5 Port Openline Vpn Industrial Gsm Internet Router
Color:
- black
Model:
- I2200
Number of USB ports:
- None
Options:
- I2200-CN Version
- I2200-EU Version
- I2200-AU Version
- I2200-Without 4G module
Basic Info
| Model No. | I2200-1 |
|---|---|
| Brand Name | OEM/ODM |
| Maximum network data transmission rate | 300mbps |
| Whether with cat function | Yes |
| Network standards and protocols | Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n |
| Wireless network support frequency | 2.4g |
| Whether to support WDS | Yes |
Product description
In addition, ComIn I2200 industrial router provides 5 x 100Mbps RJ45 network ports (one of which can be multiplexed with WAN/LAN, four LAN ports), a set of industrial phoenix terminals (serial port, GPIO, and DC power supply), and a drawer SIM/UIM card slot. It can have the serial port, Ethernet port and WIFI connected and working at the same time, providing pass-through data transmission and GPIO control functions.
ComIn I2200 IOT gateway supports remote management via the cloud management platform. It has a simple graphical interface, is convenient and quick to use. It lets you know the current status of equipment anytime, anywhere, widely used in M2M industries and the Internet of Things, such as smart grid, smart transportation, smart home, finance, Mobile POS terminal, supply chain automation, industrial automation, intelligent building, fire protection, public safety, environmental protection, meteorology, digital medical treatment, telemetry, military, space exploration, agriculture, forestry, water, coal mine, petrochemical, and other fields.
Features
Ruggedized Industrial Design
ComIn I2200 4G industrial router adopts stable performance industrial-grade 32-bit MIPS processor, with enterprise-level data communication processing capability, built-in 128MB system memory, WIFI supports 2.4GHz 802.11n protocol and provides a maximum rate of up to 300Mbps. In addition, the product adopts the metal casing to provide isolation protection, which is especially suitable for industrial control field applications. The wide voltage input design is 6~36VDC, the standard 12VDC power input, and the built-in power reverse protection.
Stability and Robustness
ComIn I2200 4G industrial router adopts dual watchdog design to ensure the stability of the device and support long-term operation. It can keep long operation hours without human interference. The system has a failsafe mechanism to take care of the WAN/Cellular connection, improving uplink time and preventing loss in communication. All the Ethernet ports have built-in 1.5KV magnetic isolation protection and the SIM holder has built-in 15KV ESD protection, the power Input has reverse-voltage and surge protection as well as lightning protection (optional) in the antenna connectors.
User Friendliness
ComIn I2200 4G industrial router provides standard RS232/RS485, Ethernet and WIFI interfaces, which can directly connect serial devices, Ethernet devices and WIFI devices. The standard wired WAN port supports PPPoE protocol and can be directly connected to ADSL equipment. The device is an intelligent data terminal, which can enter the data transmission state when it is powered on. It supports a powerful cloud management platform, which is convenient for multi-device management (optional). It is easy to use and flexible. It supports multiple working modes and is convenient for system configuration. and maintenance (including local, remote web, and cloud platform management).
Specification
|
Model |
ComIn I2200 |
|
|
CPU |
32bit MIPS Dual Core Industrial Grade Network Processor |
|
|
System Memory |
128MB DDR2 RAM (Optional 256MB Max) |
|
|
Flash |
16MB SPI Flash (Optional 32MB Max) |
|
|
Wi-Fi |
2.4GHz IEEE 802.11n MIMO |
|
|
Interfaces |
WAN |
1 x 10/100Mbps FE RJ45 Port, Auto MDI/X, with 1.5KV Magnetic Isolation Protection |
|
LAN |
4 x 10/100Mbps FE RJ45 Port, Auto MDI/X, with 1.5KV Magnetic Isolation Protection (Default) |
|
|
Terminal Block |
2.54mm Standard Industrial Terminal Block. Support Serial RS232/RS485, DC Power Input, GPIO |
|
|
SIM |
1 x Drawer-Type SIM Card Holder, Support Standard 1.8V/3V USIM/SIM Card, 15KV ESD Protection, Support Hot-Swap, Support Built-in SIM Card (eSIM) |
|
|
Power |
Standard DC Power Input Jack, Reverse-Voltage Protection, and Surge Protection |
|
|
Reset |
1 x Factory Reset Button |
|
|
Antenna |
2 x Standard SMA / RP-SMA Antenna Port, 50 ohm |
|
|
Indicators |
PWR LED Indicator x 1 |
|
|
SYS LED Indicator x 1 |
||
|
WIFI LED Indicator x 1 |
||
|
NET Status LED Indicator x 1 |
||
|
CELLULAR Strength LED Indicator x 3 |
||
|
Network Port LED Indicator x 5 |
||
|
Power Input |
Power Type |
12VDC/1A |
|
Power Range |
6V ~ 36VDC |
|
|
Power Consumption |
<450mA (12V), Typical 210mA @ 12V |
|
|
Watchdog |
Built-in Hardware Watchdog, Auto Self-Check, Auto Failure Recovery |
|
|
EMC |
Electrostatic: EN61000-4-2, Level4 |
|
|
Radiated Electric Field: EN61000-4-3, Level4 |
||
|
Pulsed Electric Field: EN61000-4-4, Level4 |
||
|
Surge: EN61000-4-5, Level3 |
||
|
Conducted Disturbance: EN61000-4-6, Level4 |
||
|
Power Frequency Interference: EN61000-4-8, Horizontal/Vertical 400A/m (>Level 4) |
||
|
Shock Wave Immunity: EN61000-4-12, Level4 |
||
|
Enclosure |
Metal Casing, Safe Isolation Between Casing and System, Especially Suitable For Industrial Control Field Applications |
|
|
Dimensions |
130mm x 135mm x 26mm (Exclude Antenna and Mounting Sets) |
|
|
Weight |
Approx. 445g |
|
|
Environment |
Operating Temperature: -35°C to 75°C |
|
|
Storage Temperature: -40°C to 85°C |
||
|
Operating Humidity: 10% to 95% RH Non-condensing |
||
|
Storage Humidity: 5% to 95% RH Non-condensing |
||
|
Firmware |
Linux SDK |
|
