5 Tons Waste Tire Recycling To Oil Machine

Technical parameters of the 5 Tons Waste Tire Recycling To Oil Machine:

Model	Raw material	Structure form	Cooling system
LJ-8	Waste tire, plastic, rubber	Horizontal	Water cooling
Heating method	Oil output rate	Power	Installation
Directly	45%	15.5KW	Foundation
24 hours processing capacity	24 hours oil output	Work pressure	Host speed
6-8 tons raw materials	2.5-3.2 tons fuel oil	Atmospheric	0.4r\min
Transport	Reactor size	Working form	Weight of reactor
External gear drive	2200*6000mm	Batch	28 tons

Main components of the 5 Tons Waste Tire Recycling To Oil Machine:

 a. Host horizontal rotary pyrolysis processor.

b. Feeding system

c. Pressure and temperature alarm system

d. Secondary catalytic tower

e. Automatic slag removal system

f. Central electronic control system

g. Tank cooling system

h. Gas heating system (exhaust gas treatment system)

i. Dust and dust removal system

Features of the 5 Tons Waste Tire Recycling To Oil Machine:

a. In the design of pyrolysis key device, completely overcome the local heat uneven, easy to break, low yield, short life and other unfavorable factors of the current vertical flat bottom pyrolysis plant.

b. With fast and practical feed and slag system.

c. Efficient gas heating system. In the process of refining, when the heated gas reaches 150 degrees Celsius, it will produce a lot of gas which can not be liquefied in normal temperature and pressure methane to butane.These gases are fully burned by specially designed gas nozzles, will produce a lot of energy which greatly saves energy.

d.Flue dust removal system has a desulfurization dust cather(qualified), equipped with two ways water impact cyclone dust removal chamber, which can ensure the discharge of flue outlet reach safe discharge standard.

Exporting experience of the 5 Tons Waste Tire Recycling To Oil Machine:

America:	Brazil, Canada, Colombia, USA,
Middle East:	Dubai, Iran, Jordan, Saudi Arabia, Turkey
Europe:	Albania , Bosnia and Herzegovina
Asia:	Afghanistan, India, Malaysia, Pakistan, Philippines, South Korea, Vietnam, Myanmar,Thailand, Uzbekistan
Africa:	Ghana, Mozambique, Zambia
