Technical Parameter

1. Applicable standards: ASTM D4530, ISO10370, DIN51551, IP398, GB/T17144

2. Temperature control accuracy: 520±2℃

3. Working unit: 12 samples

4. Heating method: electric heating rod heating is convenient for maintenance

5. Connection method: high-quality stainless steel quick connector connection, no leakage

6. Pressure adjustment range: 0kPa (0kg/cm2) ~ 392kPa (4kg/cm2)

7. Flow adjustment range: 100ml～1000ml/min;

8. Specification of waste liquid collection bottle: 200ml, glass bottle with screw interface

9. Working power supply: AC220,240V 50,60HZ

10. Power of the whole machine: 2KW

11. Instrument size: 550*500*590mm

12. Net weight: 35KG

Features

1. 5-inch TFT color LCD display, screen resolution: 800*480;

2. English operation interface, touch screen operation, convenient and quick;

3. Automatic control of temperature rise and flow, and real-time display of experimental progress;

4. Using embedded operating system, the work is stable and reliable;

5. High temperature safety protection;

6. The quality of the input sample tube and sample can be edited and input;

7. Automatically calculate the residual carbon value;

8. Store 100 groups of historical data for easy query.

9. Historical data can be queried by date.

10. The diameter of the air inlet of the coke box: 1mm (12 in total)
