Performance Parameter

Light Source

LED White light

Image sensor

640*480 pixels

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥20%

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes, including GS1 DataBar? linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision Barcode Depth of Field

3.34mil CODE 128 10mm—60mm

5mil CODE128 5mm—90mm

3.34mil EAN-13 10mm—55mm

5mil EAN-13 5mm—85mm

13.34mil EAN-13 20mm—190mm

5mil PDF417 5mm—75mm

10mil PDF417 5mm—190mm

15mil PDF417 10mm—200mm

10mil DM 5mm—100mm

20mil DM 5mm—210mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Physical characteristics

Color available

Black

Dimensions（L*W*H）

71*107*158mm

Weight

157g

Cable

2m

Electrical Parameter

Current

Working current（Standard): < 270 mA  Standby current（Standard): < 35 mA

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Particulate and water sealing

IP52

Temperature

Operation: -20 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Interfaces

Interfaces

RS-232; USB HID; USB COM; HID POS available as per customer’s needs

Warranty

Warranty

2 years
