Chuangjia Electrical steel
Chuangjia Electrical steel
Chuangjia Electrical steel
Chuangjia Electrical steel
Chuangjia Electrical steel
Chuangjia Electrical steel
Chuangjia Electrical steel

Video

1 / 7

Chuangjia Electrical steel

  • $2.00

    ≥1000 kilogram

  • $0.92

    ≥25000 kilogram

  • $0.88

    ≥200000 kilogram

Options:

  • EI-240
  • EI-210
  • EI-195
  • EI-182
  • EI-168
  • EI-162
  • EI-152.4
  • EI-150
  • EI-144
  • 133.2
  • EI-132
  • EI-120
  • EI-114
  • EI-108
  • EI-105
  • EI-96
  • EI-85.8
  • EI-84
  • EI-78
  • EI-76.2
  • EI-75
  • EI-68
  • EI-66
  • EI-60
  • EI-57
  • EI-54
  • EI-50
  • EI-48
  • EI-42
  • EI-41
  • EI-35
  • EI-30
  • EI-28
Get Latest Price

Basic Info

Model No.
Brand Name
Type Non-oriented Silicon Steel, Non-oriented silicon steel
Technique Cold Rolled, Cold Rolled
Thickness 0.27 - 0.5 mm, 0.5mm
Surface treatment Coated
shape Ei Lamination
standard Aisi
Place of Origin Jiangsu, China, China
Model Number EI-28-300
Tolerance 0.02
Processing Service Bending
Grade silicon steel
Color Gray
Material CRNO 50W470/600/800
Certification ISO9001:2008
Application Transformer core
Show More

Product description

?Chuangjia Electrical steel

Chuangjia Electrical steel
????????????????????????? Date sheet?? (Single phase series Unite:mm)
Type A B C D E F G H I J K Hole(Φ)
EI-28 28 25 8 4 6 17 21 ? ? ? ? ?
EI-30 30 25 10 5 5 15 20 25 ? ? ? ?
EI-35 35 29.5 9.6 5 7.7 19.5 24.5 5 ? ? ? ?
EI-41 41 33 13 6 8 21 27 ? ? ? ? ?
EI-42 42 35 14 7 7 21 28 7 35 ? ? 3.5
EI-48 48 40 16 8 8 24 32 40 ? ? ? ?
EI-50 50 42 14 9 9 25 34 ? ? ? ? ?
EI-54 54 45 18 9 9 27 36 9 ? ? ? ?
EI-57 57 47.5 19 9.5 9.5 28.5 38 9.5 ? ? ? ?
EI-60 60 50 20 10 10 30 40 40 ? ? ? ?
EI-66 66 55 22 11 11 33 44 44 55 ? ? ?
EI-68 68 58 22 11 12 34 46 11 57 ? ? 5.5
EI-75 75 62.5 25 12.5 12.5 37.5 50 50 62.5 ? ? 5
EI-76.2 76.2 63.5 25.4 12.7 12.7 38.1 50.8 50.8 63.5 ? ? 5/5.5
EI-78 78 65 26 13 13 39 52 52 65 ? ? 5
EI-78 78 67 22 14 14 39 53 14 64 ? ? 5
EI-84 84 70 28 14 14 42 56 51 70 ? ? 5
EI-85.8 85.8 71.5 28.6 14.3 14.3 42.9 57.2 14.3 ? ? ? ?
EI-96 96 80 32 16 16 48 64 44 80 64 8 6
EI-105 105 87.5 35 17.5 17.5 52.5 70 17.5 70 87.5 8.75 6
EI-108 108 90 36 18 18 54 72 18 ? ? ? ?
EI-114 114 95 38 19 19 57 76 76 95 ? ? 7
EI-120 120 100 40 20 20 60 80 80 100 ? ? 7
EI126 126 105 42 21 21 63 84 ? ? ? ? ?
EI-132 132 110 44 22 22 66 88 22 110 88 11 7
EI-133.2 133.2 111 44.4 22.2 22.2 66.6 88.8 88.8 111 ? ? 7
EI-144 144 124 40 26 26 72 98 98 118 98 ? 8
EI-150 150 125 50 25 25 75 100 100 125 100 12.5 8
EI-152.4 152.4 127 50.8 25.4 25.4 76.2 101.6 101.6 127 101.6 ? ?
EI-162 162 135 54 27 27 81 108 27 135 108 ? 8
EI-168 168 140 56 28 28 84 112 28 140 112 ? 10
EI-180 180 150 60 30 30 90 120 120 150 120 ? 9
EI-182 182 157 56 30 33 91 124 30 157 124 ? 8
EI-192 192 160 64 32 32 96 128 128 160 ? ? 10
EI-195 195 162.5 65 32.5 32.5 97.5 130 32.5 162.5 130 ? 10
EI-210 210 175 70 35 35 105 140 35 175 140 ? 10
EI-240 240 200 80 40 40 120 160 160 200 160 ? 12

?
???? ?????Note:Burr tolerance 0.02MM,Dimensional tolerance±0.01mm

?

?????????????????????????????? Date sheet?? (Three phase series Unite:mm)
TYPE A B C(Long) ?C(short) D E Hole NOTE
NO. (Φ)
EI-16 80 16 48 40 16 16 4 8 ?
EI-20 100 20 60 50 20 20 4 8 ?
EI-22 110 22 66 55 22 22 4 8 ?
EI-25 125 25 75 62.5 25 25 6 5.5 ?
EI-28 140 28 84 70 28 28 4 8 HIGH SPEED
EI-30 150 30 90 105 30 30 4 8 HIGH SPEED
EI-32 160 32 80 80 32 32 4 7 ?
EI-35 175 35 105 87.5 35 35 4 8 HIGH SPEED
EI-36 180 36 90 90 35 35 6 8 ?
EI-38 190 38 114 95 38 38 6 8 HIGH SPEED
EI-40 200 40 120 100 40 40 6 10 ?
EI-44 220 44 132 110 44 44 6 8 ?
EI-45 225 45 135 112.5 45 45 4 11 ?
EI-50 250 50 150 125 50 50 6 11 ?
EI-56 280 56 168 140 56 56 4 8 ?
EI-60 300 60 180 150 60 60 6 14 ?
EI-70 350 70 210 175 70 70 4 13 ?
EI-80 400 80 240 200 80 80 4 14 ?
EI-90 450 90 270 225 90 90 4 14 ?
EI-100 500 100 300 250 100 100 4 14 ?

?
? Note:Burr tolerance : 0.02mm,Dimensional tolerance : ± 0.1mm
? ? ? ? ? ? ? ? ? ?
? Contact: ? ? ? ? ? ? ?
? sandy(at)jycjdq.com ? ? ? ? ? ?
? sandychan(at)163.com ? ? ? ? ? ?
? ? ? ? ? ? ? ? ? ?
? Wechat:0086 159 9532 9060 ? ? ? ? ?
? Whatsapp&Ding:0086 136 2152 3395 ? ? ? ?
