Basic Info

Model No.
Brand Name
Mould Size	According to the plastic product/3D drawing
Mould Base Steel	S50C
Quality Certification	ISO9001:2015, SGS, TüV
Mould Packing Method	Wooden Box
Place Of Origin	Injection Mold Suppliers China
Product Color	According to customer requirements/3D drawing
Mould Shipping Method	By sea, by air or according to customer requirements
Inspection Certification	FAI, CPK, IQC, IPQC, OQC.

Product description

This is a set of Electronics Components Mold. Based on the symmetrical cavity design and the fine detailing, this mold is intended for of medical components. This mold integrates a pneumatic-driven mechanism and precision-guided sliders, which demand exceptional alignment accuracy and synchronized motion. One of the most significant challenges lies in balancing the cooling system across multiple cavities while ensuring uniform part quality. The mold is made of high-quality mold insert steel H13 and the hardness of the steel reaches HRC48-52, the life of the mold can exceed 500,000 shots or more when the mold is well maintained.?

Thin-wall areas pose a significant risk of deformation under injection pressure, thus material selection and heat treatment must be handled with care. Achieving consistent product quality over long-term production requires careful control of flatness, dimensional tolerances, and mold rigidity. Our company is very experienced in? Aircraft Plastic Mold, car part mold, unscrewing injection mould.

Mould Name: Complex Core Features Electronics Components Mold

Gate Way: Point Gate

Mould Insert Steel: H13

Runner: Cold Runner
