Addressable Input Module

The TX7200 Addressable Input Module is used to acknowledge normally open monitor signal from interface equipment then sending communication signal to the control panel, ideally for monitoring sprinkler system, pressure switch, position switch, signal valves and other third party equipment such as conventional panel.
The unit manufactured base on the requirement of EN 54 part 18, European Standard. The unit is aesthetically pleasing with unobtrusive design that will complement modern building designs and its plug-in type assembles make installation and maintenance more convenient to the installer. The unit incorporates an intelligent processor that provides automatic monitoring for both open and short circuit of the input signal line. The TX7200 Input Module is compatible to the TX7004 Analogue Intelligent Fire Alarm Control Panel, produced by single manufacture T&A, to avoid addressable communication compatibility problem.

Feature and Benefits

• EN54-18 Compliance LPCB Pending
• Built-in MCU processor and digital addressing Fire or Supervisory signal configuration
• Input cable monitored Normally open configuration LED status indicator
• Loop powered device Aesthetically pleasing design
• Surface mounting with fix base for simple installation

Technical Specification
