? ? ? ? ? ? ? ??Loading and unloading pump ?Technical Data ? ? Application Scope YHCB?series?of?on-board?arc?pumps?are?mainly?used?in?conveying?viscosity?in?5?to?1500?CST,?the?temperature?is?below?80?°C
and?not?containing?solid?particles,?non-corrosive,?various?oil?medium.?Gear?selection?of?special?material,
can?play?the?role?of?explosion-proof.
Arc?gear?pump?can?be?installed?in?the?car,?with?the?help?of?take?a?power?output?shaft?of?automobile?gearbox. ? Application? ? ?? Structure& Operation Theory ? ? ?? Working Principle Driving gear (outside rotor) with internal tooth drives the internal rotor and turns in same direction in the full closed pump body. The inlet is from the outlet. When it turns, negative pressure formed at the suction port, the liquid inlet and being take to the outlet by rotor, then the liquid is impelled from the discharge port and the gears mesh. The transportation of liquid finished. ? Structure Feature As figure, the pumps are mainly composed of internal rotor, outside rotor, shaft, pump casing, front cover, seal, bearing etc. The pump' seal adopts packing seal or mechanical seal. When the delivered medium is high temperature, high viscosity or strong corrosion, packing seal should be adopted. When the delivered medium is easy crystal linic, we can design the heat preservation jacket in pump casing and front cover in order to melt the medium with steam when working. The pump can be also fitted with the safety valve. The pump set is composed of the pump, motor and baseplate. The driving way is belt wheel driving or coupling driving. ? Package& Transportation ? ? ? ?? Company Introduction Botou Jinhai Pump Manufacture Co., Ltd is a leading and professional company with many years' experience in pump manufacturing. We specialize in products for many kinds of liquids (such as water, gasoline, lubricant, diesel, acid liquid etc.) Such as Oil Pump, Gear Oil Pump, Lubricant Pump,Stainless Steel Gear Oil Pump, Bitumen Pump, Self Priming Pump, Hot-transfer Oil Pump, Centrifugal Pump etc. Our company can also produce qualified products according to customer's customization.
