Optical Communication: Exploring Laser Transmitter and Receiver Technologies

$100.00 ~ $1000.00 / piece

Get Latest Price

You might also like

TV Broadcast Transmitter: Enhancing Your TV Signal Experience

1 piece (MOQ)

1550nm 10dBm CATV Directly Modulated Optical Transmitter

1 piece (MOQ)

YOUXIN CATV 1550nm Direct Modulation Optical Transmitter: High-Efficiency Fiber-Optic Solution

1 piece (MOQ)

Waterproof CATV Indoor Outdoor Fiber Optic Transmitter and Receiver: Your Reliable Solution for Robust Signal Transmission

$100.00

1 piece (MOQ)

High-Quality 1310nm Fiber Optic Laser Transmitter for HFC CATV Networks: Supplier and Price Information

1 pack (MOQ)

1310nm DFB Optical Transmitter for CATV: 20km RF Fiber Optic Solution

$200.00

2 piece (MOQ)

High-Frequency TV Signal Transmitter and 1310nm Optical Transmitter Technology

$500.00

1 piece (MOQ)

High-Power 1310nm Fiber Optical Transmitter with Automatic Gain Control (AGC) - Configurable from 2MW to 32MW, Featuring Dual Fan and Dual Power Supply

$100.00

1 piece (MOQ)

Direct Modulated Optical Laser Transmitter at 1310nm with Power Range of 2-32MW: A Comprehensive Guide

$400.00

1 piece (MOQ)

1310nm Fiber Optic Transmitter and Receiver: Enhancing Data Transmission Efficiency

$100.00

2 piece (MOQ)

Basic Info

Model No.
Brand Name
Place Of Origin	Zhejiang, China
Brand Name	YOUXIN
Model Number	OT1550E-xx
Operating Wavelength	1540~1563nm&ITU-TG.692
Work Bandwidth	47~862 MHz
Input Level	18~28dBmV
Laser Type	1550nm DFB LD
RF Port	F-Female
Power Supply	90 ~ 260VAC,50/60Hz
Network Management	RJ45, RS232, RS485
Dimension	48544745mm
Application	HFC, FTTx
Certification	CE/RoHS/ISO9001:2008, ce

Product description

Detailed Info

Externally modulated optical transmitter with SNMP management, indoor, 1550nm, 2 output port, ≥7mW output optical power, 47~862MHz, SBS, 13/16/18dBm or adjustable, imperial F type female port, FC/APC or SC/APC connector, RJ45 and RS232 port, VFD, 19" 1U.

Features:?????????????????????????????????????????????????

(1) ?Narrow bandwidth (Typ.=1MHz), lower noise, DFB continuous wave laser

(2) ?The operating bandwidth is up to 47~1080MHz

(3)? Perfect index: Unique innovation technology, provide excellent CNR, CTB, CSO & SBS

(4)? Perfect RS232 communication interface

(5)? SNMP network management function optional

(6)? 1+1 backup power supply optional

(7) ?Casing temperature auto-control

(8)? Excellent P/P ratio

(9) ?AGC/MGC mode is optional at spot. OMI can be optimized at spot

Description

RFTV is a unidirectional analogue and digital video broadcast. It adopts high efficiency modulation mode for RF carrier wave and its economy, flexibility and bandwidth validity is beyond comparison of IPTV. By adopting EPON, GEPON or P2P access mode to realize triple-play and FTTx, RFTV broadcasting network in 1550nm optical wavelength still plays an important role and 1550nm externally modulated optical transmitter is the core equipment in this system.
