Product Description

PCBA Program Development Main Board Design.Whether it's the perfect layout of a new design, redesign of existing PCBs and/or circuits, PCB delivery, component sourcing for existing or new projects, or overseeing draft plans up to and including the assembled final product, you can rest assured.

PCB Business：

Lead Time:7-10 days for 2L

                10-12 days for 4L

                12-15 days for over 6L

PCB Basic Specifications

Brand	LDJ
Type	BMS PCB
Material	FR4(High TG,Standard TG and Teflon TG) /CEM3 / Ceramic / Aluminum /High Frequency Plate / Teflon plate etc.
Number of layer	1-20 layers (include Rigid PCB,Flexible PCB and Rigid-Flexible PCB)
Board Thickness	0.2mm-6mm
Board Thickness Tolerance	5-10%
Profile Processing	CNC Milling /V-Cut / Mold Flushes
Copper Thickness	0.5oz-6oz
Copper Weight Tolerance	±0.15oz
Min Line Width	0.075mm
Min Line Space	0.075mm
Drill Hole Szie	0.15mm-6mm
Max Board Size	1200mm*600mm
Silk Screen Min Line Width	0.15mm
Anti-welds resin	Termosetting resin / Without the gloss resin / Photosensitive resin
Certification	REACH and RoHs / CQC / IATF16949 / ISO9001 / ISO14001 / ISO45001 / ISO13485 / UL
Surface Finish	Lead Free HASL / OSP /Immersion Gold / Immersion Tin / Immersion Silver / Plated Gold etc.
Solder Mask	Green / Black / White / Blue / Yellow / Red / Coffee etc.
Impedance Control	±10%
Test Service	100%

Related Products



PCB&PCBA file requite:

1.Gerber file or Schematic diagram of printed circuit board.

2.Material,Board thickness,Copper thickness and Surface finish of PCB

   (please write in Gerber file or send data to us.)

3.BOM (list of components)

4.Number of circuits you need.
