Portable laser code printer
$8000.00
≥2400 Set/Sets
Power (Watts):
- 20w
Basic Info
| Model No. | hand held |
|---|---|
| application | Laser Marking |
| Support graphic format | Ai |
| Laser type | Co2 |
| Old and new | New |
| Whether CNC | Yes |
Product description
1. Full automatic online
2. Can it be embedded in customer SMT assembly line
3. With carbon dioxide or green laser generator
4. The width can be adjusted automatically
5. Meet SMEMA standard
6. Cooperate with CCD to improve the positioning accuracy
7. Read two-dimensional code with CCD
The equipment can realize automatic loading and unloading, positioning, marking and online code reading of PCBA board. The technical parameters of the equipment are mainly based on the PCBA industry standard SMEMA.
Main process:
Automatic loading (customer provides loading machine) - input - CCD position mark (content can be customized) - CCD reads code and automatically unloads (customer provides unloader).
The equipment adopts standard SMEMA interface, which can realize high precision automatic marking, automatic loading and unloading, automatic code reading
Mainly used for PCBA industry dynamic marking (one-dimensional code, two-dimensional code, production batch number, characters, etc.)
Specification:
Serial number project parameter
one Laser CO2 10W Green light 10W
two Laser wavelength 1064nm 532nm
three Minimum point size 0.5mm 0.05mm
four Marking range 50*50mm
five Marking length 100mm ± 2mm
six Applicable PCBA size 50*50mm-460*460mm
seven Cooling system Air cooling
eight life 20000 hours
nine Applicable base thickness 0.6-3mm
ten Suitable line height nine hundred ± 20mm
eleven System repeat positioning accuracy ± 0.15 mm（CCD location）
twelve Gas source 0.6-0.8Mpa
thirteen power supply 220V
fourteen power waste ＜ 2.2 KW
fifteen Equipment size (L * w * h) 950mm × 1600mm × 1700mm(H)
sixteen weight 600KG
seventeen IP level IP 54
- 5yrs
- Manufacturer
- OEM service
