FEATURE
*Drying speed is high. When liquid raw material is atomized, the surface of the material will be enlarged greatly. In the hot air flow, 95% - 98% of water can be evaporated instantly. The time of completing the drying just only several seconds. This is especially suit for drying heating sensitive material.
*Finished products are granuled ball with uniform size; ¬humidity and solubility are good, high quality and high purity.
*Wide range of applications, strong adoptability to raw materials, depend on the characteristics of raw material, It can apply hot air or cooling air to dry and granulate.
*Simple and stable operation, brief and convenient control, easy to achieve automatic operation.





Technical parameter Of Egg Powder Pressure Spray Dryer

YPG-I

Item   type	YPGI-12	YPGI-14	YPGI-16	YPGI-24	YPGI-28	YPGI-36
Capacity of moisture(kg/h)	25	70	100	150	200	400
style of heating	Steam+heat additionalor oil, gas hot air furnace
diameter of towe (mm)	1200	1400	1600	2400	2800	3600
overall dimensions (m)	5×4×10	6×4×12	6×4×13	8×4.5×19	10×5×20	12×5×25
Inlet air temperature(℃)	300~350

YPG-II

item   type	YPGII-36	YPGII-40	YPGII-45	YPGII-50	YPGII-56	YPGII-80
capacity of moisture(kg/h)	380	500	600	750	1000	2000
style of heating	Steam+heat additionalor oil, gas hot air furnace
diameter of towe (mm)	3600	4000	4500	5000	5600	8000
overall dimensions (m)	The index can be affirmed in accordance with practical conditions
Inlet air temperature(℃)	300~350

 Pre-service

Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.

1. Introduce the product to the customer in detail, answer the question raised by customer carefully;

2.Make plans for choice according to the needs and special requirements of users in different sectors;

Sale service

1. Ensure product with high quality and pre-commissioning before delivery;

2. Delivery on time;

3.Provide full set of documents meet customer`s requirements.

After-sale service

Provide considerate services to minimize clients` worries.

1.Assist clients to prepare for the first construction scheme;

2.Install and debug the equipment;

3.Train the first-line operators;

4. Examine the equipment;

5.Take initiative to eliminate the troubles rapidly;

6.Provide technical support;

7.Establish long-term and friendly relationship.

Service commitment

1. Provide clients one-year warranty to make sure the machine work well;

2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;

Principle of work matters that should be known before order:

1. What is Particle liquid name and materials property, solid contents or water contents, viscosity, surface tension and PH value.

2. Powder material contents after the drying, permissible residual water contents, particle size, and permissible maxing temperature.

3. Energy that can be supplied: steam pressure supply capacity, electricity capacity, fuel coal, oil and air capacity?

4. Control requirement: how many celcius the inlet air temperature need to be controlled?

5. Powder collection requirement: whether or not the bag type collector should be mounted and what is the requirement of the environment for discharging the exhausted gas?

6. Other special requirements.
