Schuko Garden Waterproof Socket has sensor control for day/light recegnition, suitable for installation outdoors, in recent years there has been a dramatic increase in the use of mains-powered electrical equipment in domestic gardens. More and more people have electric lawn mowers and electric hedge trimmers. With warmer summers, barbecues are increasingly popular, among them electric versions. Many householders like to celebrate regular and special events with decorative outdoor lighting and, occasionally, for parties, will set up sound systems in their gardens.

Features

·Wide voltage input range: 100-264V

·Working frequency: 50/60HZ

·Water proof level: IP54

Application

·Outside Fountain

·Outside landscape lamp

·Outside Garden light

Schuko Garden Waterproof Socket

Parameters

AC Working voltage range: 100V~264V

AC Working frequency: 50/60HZ

AC Rated output current: 10A(2PCS sockets total 10A)

AC Max output current: 16A(2PCS sockets total 16A)

Waterproof level: IP54

AC wire diameter: 1.5mm2

Working temperature: -35℃~+65℃

Installation

·  Carefully unpack contents and check to make sure all parts are present. Following this insert the plastic stake plug into the bottom hole of the sockets.

·  Choose a suitable location for the AC socket giving careful consideration to the nearest suitable outlet, trip hazard etc. Push the socket firmly into the ground and plug in the socket.

·  Lastly, insert the appliance into the 2 sockets.

·  There are two different power options, with the switch on the backside.

  On: The power will always be on.

  Sensor: The power will only be on from dusk till dawn.

Schuko Garden Waterproof Socket

Attention

·  This product has a waterproof level of IP54, this means it can with stand splashes of water, but not large bodies of water.

·  This product contains 2 built-in sockets. If you are only using one socket the rated current can reach 10A, with a max. current of 16A, but reaching 16A for extended periods of time can damage the socket and internal components, therefore must be avoided.

·  If you use 2 sockets at a time the max. current should not exceed 16A.
