Basic Info
| Model No. | BT600LC/YZ1515X |
|---|---|
| Brand Name | CR |
| Flow Rate | 0.007—2280ml/Min |
| Control method | Touch Screen + Keypad |
| Model | Bt600lc/Yz1515x |
| Display Mode | Lcd(english And Chinese Optional) |
| Speed | 0.1-600rpm |
Product description
For example, in medical or laboratory devices, peristaltic pumps can be used for processing of sterile fluids, dialysis, filtration, or bio-processing, Our model BT300LC Constant Flow Peristaltic Pump is very popular in hospital, it has high accuracy as it’s also stepper Motor Peristaltic Pump. In food, agriculture, or disinfection processes, they can be used for dispensing food or beverages, vitamins or chemicals. It also can be used for wastewater treatment or other environmental application such as condensate removal in gas analysis. So if you want variable peristaltic pump with high flow/medium flow/micro flow, choose Chuangrui brand is the best choice.
|
Parameter Model : BT600LC/YZ1515x |
|
|
Speed |
0.1-600rpm |
|
Speed resolution |
0.1rpm |
|
Flow rate |
0.007-2280ml/min |
|
Control Method |
Touch screen + keypad |
|
Display Mode |
LCD(English and Chinese optional) |
|
Power supply |
AC220V±10%(standard) or AC110V±10%(optional) |
|
External control |
Start & stop, direction control, speed control( 0-5v, 0-10v, 4-20mA optional ) |
|
Communication interface |
RS232 and RS485, support MODBUS protocol mode |
|
Foot pedal |
Yes |
Features of Programmable Peristaltic Pump:
·1.Storage function-user data storage function:(9 sets of data) .
·2.External control function-Multiple mode selection: communication mode, analog mode,foot switch control.Provide customized services.
·3.Memory function-data will be stored in time after power off. When power supply is restored, the Metering Peristaltic Pump can remember the parameter Settings before power off, which is more safe and reliable.
·4.Calibration function-intelligent flow calibration: after setting the target flow, input the actual flow value, and the system will automatically carry out flow calibration to ensure the flow accuracy
5.Full speed function-one button to control full speed operation, used for quick cleaning, filling and emptying tubes, etc
6.Suckback function-By setting Suckback angle and Suckback speed to prevent liquid dripping and ensure fluid accuracy.
7.lock screen function-lock screen design, error proof touch, application more secure.
8.Display function-real-time animation of the operation interface shows the running state and working parameter.
9.Touch-screen function-3.5-inch color LCD screen,( 59345016, 59331639,English and Chinese optional) , touch-screen operation, intuitive and intelligent.
10.Whole housing design-stainless steel housing,sturdy and durable , multi-face seamless whole housing design, Long service life, high cost performanc
