-Product Information China Tungsten carbide manufacturer and supplier,We are good at processing carbide tools and wear parts according to drawings. Our cemented carbide products are widely used in oil and gas, mining and textile industry, high pressure pump and drilling industry, wire and pipe manufacturing, battery and automotive industry, powder Metallurgy and ceramics industry, mold and machinery industry.
-Standards compliant

Our tooling is made from proprietary grades of tungsten carbide. It offers superior toughness, along with resistance to:
·Abrasion
·Compression
·Corrosion
·Deflection
·Erosion
·Torsional Stress
·Wear

Our finishing services provided at the Chengdu plant in Sichuan Province include：

Grinding (Steel & Carbide)

·Turning/Hard Turn
·Applications Engineering
·Reverse Engineering
·Special Coatings
·Troubleshooting

By synthesizing our knowledge and experience in metallurgy and engineering, we consistently deliver superior tooling.

-Material

YG6 YG7 YG8 YG9 YG10 YG15 YG20X（Can also be made according to customer requirements）

    （Tungsten carbide (WC), also referred to as cemented carbide, is a composite material manufactured by a process called powder metallurgy. Tungsten carbide powder, generally ranging in proportion between 70%-97% of the total weight, is mixed with a binder metal, usually cobalt or nickel, compacted in a die and then sintered in a furnace.
The term “cemented” refers to the tungsten carbide particles being captured in the metallic binder material and “cemented” together, forming a metallurgical bond between the tungsten carbide particles and the binder (WC – Co), in the sintering process. The cemented carbide industry commonly refers to this

material as simply “carbide”, although the terms tungsten carbide and cemented carbide are used interchangeably.）

	WC+Other	Co	Density	Hardness	T.R.S.	Impact Strength
	(±0.5%)	(±0.5%)	(g/cm3)	(HRA)±0.5	(kfg/mm2)	(kgf-m/cm2)
Medium	91	9	14.61	89.3	340	0.52
	88	12	14.31	88.3	340	0.58
	85	15	13.95	89.3	360	0.7
Coarse	80	20	13.4	85.3	270	0.8
	80	20	13.58	84	280	0.85
Fine	90	10	14.35	91.8	380	0.3
	88.5	11.5	14.15	92.2	380	0.35
	87	13	14.15	90	350	0.38
Non-magnetic	86	14%Ni.	14.15	86.5	260	0.39
Ultrafine	97.2	-	15.12	94.5	240	0.18
