High quality Underground pipe gallery post machine During the cold bending process, the sheet metal gradually forms into the final shape, and when the material passes through the mill, Underground pipe rack machine is formed by a rotating roller. The objective of roll design is to shape the desired product within a given tolerance with a minimum number of forming steps, the minimum number of passes. The advantages of Underground pipeline post machine are: it can produce various ultra-thin, ultra-wide and complex profiles which can not be produced by rolling; Underground pipeline rack machine can save metal materials and has good mechanical properties. Commonly used processing methods are roll bending, bending, bending and bending.

 Our main products include C purlin machine, Z purlin machine, CZ purlin machine, Storage Rack Making Machine, Storage Shelf Rack Roll Forming Machine, Mobile Rack Making Machine, Cable Tray Roll Forming Machine, Purlin Roll Forming Machine, Welded Pipe Making Machines, Highway Guardrail Roll Forming Machines, Metal Expanded Mesh Production Lines, C/z Purlin Machine, Scaffolding Walk Board Machine and so on, we can customize machines according to customers' requirements, If you have any further question of our Roll Forming Machine, please feel free to contact me.

1. The Chart of Process flow

Manual de-coiler --- Leveling Machine ---Servo Feeding machine ----Punching machine----Roll Forming Machine------Computer Control Cabinet---Automatic cutting Mechanism ---Run-out Tables

2. Technical specification and details

(1) Hydraulic Ue-coiler

Un-power: manual de-coiler; Max. Capacity: 5T

Manual power expands the coil inner surface.

(2) Roll forming machine

Description
Product Name	Photovoltaic stents roll forming machine
Machine Size	15000mm*2000mm*1800mm
Machine Weight	About 20 T
Frame Materials	450H steel
Forming Shaft	Diameter	100mm
	Material	45# quenched and tempered material
Forming roller	45# Forging Hard Chrome Plating
Cutting System	Hydraulic Cutting
Main Engine power	22 KW with cycloidal reducer
Forming Rows	22 rows
Forming Speed	8-12m/min
Pressing Thickness	2-2.5mm
Coder	Wuxi "rip" or "Xin Ya"
Switch	" CHINT "or" delixi"

Equipment for Reference:

(3) Hydraulic Cutting

1) Adopts post cutting, Stop to cut;

2) The cutting blade material is Cr12 with quenched treatment.

3) Cutting frame has been heat treatment to avoid final product deformation, cutting length tolerance ±2mm.

(4) Hydraulic station

1) It supplies the power for the hydraulic cutter.

2) All hydraulic accessories are all use Chinese famous brand products.

(5) PLC Control System

1) This system uses Delta PLC to control the all working actions. Production quantity and each piece length will be automatically measured. It is convenient to control the roll forming machine.

2) Delta converter adjusts speed technology, realize the automatic production.

3) Text screen is input and cancelled the working data.
