Basic Info
| Model No. | GRA31A |
|---|---|
| Brand Name | Ningbo GDoor |
| Material | Aluminum Alloy |
| Type | Revolving |
| Open Style | Revolving |
| Opening Type | Induced |
| Special Function | Security |
Product description
Ningbo GDoor three-wing automatic revolving doors have two driving models: top driving and bottom driving. Manual mode, automatic mode, and automatic/manual mode are available for Ningbo GDoor three-wing revolving doors.
Ningbo KBB
Operation features
1. Continuous working mode
2. Go/Stop working mode
3. Remote control function
1. Anti-squeeze
2. Anti-strike
3. Force-sensitive Control
4. Torque Control
5. Panic breakout system
6. Handicap
7. Night Security Door
8. Special Load-Bearing Structure
9. Vertical/horizontal safety switch
Technical Data
1. Power supply : 220 V/AC±10%, 50 HZ
2. Decorative Light :12 V/AC, 120W/240W
3. Rated power : 530 W
4. Motor power : 180 W
5. Lighting power : 300W
6. Control system power : 50 W
5. High speed adjustment range(revolving door) : 1~4r.p.m.
6. Low speed adjustment range(revolving door) : 0.5~2.5 r.p.m.
Specifications:
1. Inner Diameter: 1800mm, 2100mm, 2400mm, 2700mm, 3000mm, 3200mm, 3600mm
2. Outer Diameter: 1888mm, 2188mm, 2488mm, 2788mm, 3088mm, 3288mm, 3688mm
3. Total Height: 2700mm, 2700mm, 2700mm, 2700mm, 2700mm, 2700mm, 2700mm
4. Inner Height: 2400mm, 2400mm, 2400mm, 2400mm, 2400mm, 2400mm, 2400mm
5. Opening Width: 805mm, 955mm, 1105mm, 1255mm, 1405mm, 1510mm, 1705mm
