Automatic CNC Lathe Machine with Program Control System
Automatic CNC Lathe Machine with Program Control System
Automatic CNC Lathe Machine with Program Control System

Video

1 / 3

Automatic CNC Lathe Machine with Program Control System

$7000.00 ~ $15000.00 / Set/Sets
Get Latest Price

Basic Info

Model No. SF-150
Brand Name
Application Metal
Process Usage Metal-Cutting CNC Machine Tools
Movement Method Linear Control
Control Method Open-Loop Control
Numerical Control CNC/MNC
Processing Precision ±0.05mm
Performance Classification Economical CNC Machine Tools
Condition New
Show More

Product description

Automatic CNC Lathe Machine with Program Control System

CNC machine tools have the following characteristics:

1. Improve working conditions
NC machine tool is adjusted before processing, input program and start, the machine can have automatic continuous processing, until the end of processing. All the operators have to do is program input, editing, parts loading and unloading, tool preparation, processing state observation, parts inspection and other work. The labor intensity is greatly reduced, and the labor of machine tool operators tends to be intelligent work. In addition, machine tools are generally combined, both clean and safe.
2. Using the modernization of production management
The processing of CNC machine tools can accurately estimate the processing time in advance, standardize and modernize the tools and fixtures used. It is easy to realize the standardization of processing information. It has been organically combined with computer aided design and manufacturing (CAD / CAM) and is the basis of modern integrated manufacturing technology.

Automatic CNC Machine


cnc machine


SPECIFICATIONS

BASIC DATA

SF-150

MAX.SWING OVER BED

350mm

MAX.TURNING LENGTH

300mm

X-AXIS TRAVEL(AROSS)

560mm

Z-AXIS TRAVEL(LONGITUDINAL)

300mm

RAPID FEED(X&Z AXIS)

15000mm/min

SPINDLE MOTOR POWER-GSK

5.5kw

SPINDLE BORE

65mm

MAX.BAR CAPACITY

40mm

SPINDLE SPEED RANGE

50-3000rpm

TOOL SIZE(CROSS SECTIONAL)

20*20mm

POSITIONING UNCERTAINTY(P)

X:0.01mm Z:0.01mm

NET WEIGHT

1250KG

GROSS WEIGHT

1350KG

SIZE(LENGTH x WIDTH x HEIGHT)

2070mm x1510mm x1920mm




Company Overview
Shaoxing Sunfong Intelligent Equipment Inc. was founded in 2006, specializing in R&D.manufacturing and sale of machinery and equipment. Our products include: Program-controlled hydraulic automatic lathe,CNC machine lathe,Double servo high precision
