Automatic Computerized Shoe Knitting Machine

Model FENGFAN-6FS    "6F" means " Six Needle Selector"   "S" means "Shoe"

Cylinder 3 1/2"     3 3/4"     4"     4 1/2"
Number of Needles 120-220N
Rotating Speed 300-350 RPM for sock body  250-280 RPM for sock heel
Air Consumption 0.05-0.07 m3/MIN-SET
Air Pressure 0.6-0.7MPa
Voltage 380V(3-phase)/220V(2-phase)
Power  Drive Motor 31kw
Fan Motor 0.75kw
Computer 0.8kw
Weight :Net 260kg
Gross 300kg
Volume（include normal yarn creel)" 150*120*240cm
Package Size "90*75*160cm
39 sets for a 40 container,18 sets for a 20 container)"
Technical Features "Designed to make shoes"
Using LCD and touch screen, you can choose 10 different language, like Chinese, English, Russian,   Farsi, Korean, Japanese and so on."
Using automatic lubricating oil system and highly sensitive protector for yarn breaking and needle breaking."
With UPS,it can save programs when power off."
Can knit the heels and toes with different colors."
Can choose double elastic motor."
Can choose double main yarn feeder"
Can make 3D socks"
