Basic Info

Model No.	VDL400
Brand Name	BILLON

Product description

Brake disk processing machine tool

Brake disk processing machine tool (vertical and inverted vertical lathe) is combined of vertical lathe and inverted vertical lathe,which can process two sides of the workpiece at the same time.

It is suitable for all kinds of plate and shell (such as car brake disc , wheel hub, flywheel, gear blank, bearing ring , flange ,etc.) processing . Equipped with automatic up-down material, clamping, processing ,and blanking function , the machine tool can realize automatic production line.

Processing range:

It is suitable for complicated shape of medium and small batch parts processing and large quantities of parts processing that has same precision and size requirement.

Technical Parameter:

Name			Vertical and inverted vertical lathe
Specification			VDL 200		VDL 400
Items	Processing production		Under200		Under400
Processing arrangement	Max swing diameter	mm	300		500
	Max turning diameter	mm	200		400
	Max turning height	mm	350		350
			Inverted Vertical	Vertical	Inverted vertical	Vertical
Spindle	Servo main motor power	kw	5.5/7.5	5.5/7.5	42/50	15/18.5
	Max spindle speed	r/min	6000	3000	2000	2000
	Max spindle torque	Nm	36	88/191	400/570	357.5/590
Stroke	X stroke	mm	800	800	1000	1000
Stroke	Z stroke	mm	400	400	400	400
