Flywheel processing combination machine tool

Billon flywheel special processing combination machine tool can realize double processing at the same time and robot automatic up-down material, which can improve the efficiency of 80%.

Features:

1.       Electrical and integration design , reasonable structure ,and simple operation.

2.       Billon flywheel and driving wheel CNC machine tool is suitable for two-dimensional , three-dimensional processing at the same time .

3.       Fully enclosed electrical cabinets , supplemented by air loop design, good wind dust and cooling effect .

4.       Double channel control system, double frame structure, two group of independent knife line (X1Z1,X2Z2).

5.       Hydraulic power chuck workpiece clamping makes the machine convenient automatic up-down material and save manpower.

6.       The machine has centralized lubrication device and can realize lubrication at any time .

7.       The machine can realize double processing at the same time ,which can improve the work efficiency by 80%.

Technical parameters:

Model                         VT4040F   VT6570F          VT9080F

Max rotating diameter (mm)         600        800          1000

Max turning diameter (mm)          400       650            900

Max turning height(mm)             450       700           800

Max machining weight(kg)           200        800          1200
