Brazed carbide turning tool Bench lathe turning tools

Name: Brazed carbide turning tool Bench lathe turning tools
Brand: GanSu Port Logistics Co.,Ltd
Rating: 4.5 (3 reviews)

$15.00

≥10 Set/Sets
$10.00

≥11 Set/Sets

Get Latest Price

You might also like

High Precision CNC Machining Stainless Steel CNC Lathe Turning Parts

100 Set/Sets (MOQ)

high precision cnc lathe turning parts

$15.00

100 Set/Sets (MOQ)

Brazed carbide turning tool Bench lathe turning tools

pcd & pcbn turning tools milling inserts

1 Set/Sets (MOQ)

Basic Info

Model No.	PCD cut tool for V 35 ° prismatic
Brand Name
place of origin	China

Product description

The hardness of the cubic boron nitride sintered is generally 3500 ~ 4000Hv, ceramic. 2400 Hv, hard alloy 1800 Hv. High hardness brings good abrasion resistance. In general, the wear resistance of cubic boron nitride is 30 times as high as coating alloy, 50 times as much as non-coated carbide, and 15 ~ 20 times of ceramic blade.

Cubic boron nitride cutting under the high temperature of 1000 DHS C, its surface will not produce oxidation, extent of the high temperature hardness is much smaller than cemented carbide and ceramic blade, this will create conditions for high speed cutting. Cubic boron nitride chemical inertness, particularly large in neutral medium, the air is stable to acid and alkali, in 2000 DHS doesn't react with carbon and with iron clan materials in 1200 DHS C ~ 1300 DHS C doesn't response for cutting ferrous metal materials.

型號(hào)（公制）ISO	型號(hào)（英制） ANSI	刀尖半徑	切削刃數(shù)	切削方向	內(nèi)切圓A	孔徑 0d	厚度 T
VCGW070201	VCGW(1.2)1.5)(0.2)	0.1	1	N	3.97	2.3	2.38
VCGW070202	VCGW(1.2)1.5)(0.5)	0.2	1	N	3.97	2.3	2.38
VCGW080202	VCGW(1.5)1.5)(0.5)	0.2	1	N	4.76	2.3	2.38
VCGW080204	VCGW(1.5)1.5)1	0.4	1	N	4.76	2.3	2.38
VCGW110302	VCGW22(0.5)	0.2	1	N	6.35	2.8	3.81
VCGW110304	VCGW221	0.4	1	N	6.35	2.8	3.81
VCGW160402	VCGW33(0.5)	0.2	1	N	9.525	4.4	4.76
VCGW160404	VCGW331	0.4	1	N	9.525	4.4	4.76
VCGW160408	VCGW333	0.8	1	N	9.525	4.4	4.76
VCGW160412	VCGW333	1.2	1	N	9.525	4.4	4.76
VBGW110302	VBGW22(0.5)	0.2	1	N	6.35	2.8	3.81
VBGW110304	VBGW221	0.4	1	N	6.35	2.8	3.81
VBGW160402	VBGW33(0.5)	0.2	1	N	9.525	3.81	4.76
VBGW160404	VBGW331	0.4	1	N	9.525	3.81	4.76
VNMG160402	VNMG33(0.5)	0.2	1	N	9.525	3.81	4.76
VNMG160404	VNMG331	0.4	1	N	9.525	3.81	4.76
