Item

Technical Specification

Welded mesh width

(horizontal line length)

2M

Welded mesh length

(Vertical line length)

4.8M(Adjustable)

Welding points(i.e. the number of vertical lines)

14

Diameter of vertical line

8-10mm

Diameter of horizontal line

8-10mm

Minimum distance of vertical line

150mm+(Adjustable)

Minimum distance of horizontal line

150mm+(Adjustable)

Welding Speed

20-25 rows/min

(According to wire diameter, grid)

Welding transformer (welding machine)

7 sets of large water-cooled welding machines

Vertical line feeding

straightening and cutting,install pneumatic wire feeding device

Horizontal line feeding

straightening cutting, mechanical Hopper,automatic wire falling

Driving Power

variable frequency electromagnetic brake motor 5.5KW

Reducer

No. 6 cycloid needle wheel reducer

Pulling mesh power

Servo motor 2.6KW

Pressing method

Spring pressing

Welding principle

Current welding

Pulling method

Pneumatic circulation

Outputting method

By Manual

Control system

PLC.  Programmable control

Staff needs

2-3 persons

Machine weight

4.5T Approx
