Closed Loop Hall Effect Current Sensor HKC

Get Latest Price

Model No.	HKC
Brand Name	FERRTX

FERRTX Closed Loop Hall Effect Current Sensor HKC｜Zero Hysteresis & 10kHz Bandwidth

Precision Current Sensing Revolution

The FERRTX HKC Series Closed Loop Hall Effect Current Sensor delivers laboratory-grade accuracy in harsh environments. Leveraging magnetic compensation technology, it achieves ±1% linearity across DC-10kHz bandwidth – outperforming traditional DC Current Sensors in dynamic response. With reinforced 5kV galvanic isolation and -40°C to +125°C operation, it replaces bulky lem split core current sensor solutions in space-constrained applications.

Core Engineering Advantages

Zero Magnetic Hysteresis
Eliminates calibration drift vs. open-loop?hall effect current sensors
Sub-μs Response Time
5× faster than?Rogowski Current Sensors?for overcurrent protection
Wide Voltage Compatibility
4.5-24V supply range (TTL/CMOS compatible)
EMC Immunity
Withstands 100V/ns dv/dt noise in VFD environments

Critical Performance Parameters

Bandwidth: DC–10kHz (captures motor drive transients)
Accuracy: ±1% @25°C (±1.8% -40°C to +125°C)
Isolation: 5kV RMS/60s (IEC 62368-1 certified)
Response Time: <0.5μs
Current Ranges: 50A, 100A, 200A, 500A

Industry-Specific Applications

Industrial Automation

Servo motor phase monitoring (±0.8% repeatability)
PLC analog input modules
Welding equipment current control

Energy Infrastructure

Solar inverter MPPT tracking
BESS discharge control
Wind turbine converter protection

Electric Vehicles

Traction inverter current sensing
OBC leakage detection
BMS high-voltage isolation

Consumer Electronics

UPS inrush limiting
Server PDU monitoring
Industrial SMPS feedback

Product Series	IDC(A)	Supply Voltage(V)
05-HKC-EKB1	200-4000	15
20-HKC-B	50-300	12-18
HKC-2012Y1	2000-10000	12-15
HKC-B1	50-600	12-15
HKC-BS	50-600	15
HKC-BS5-0.626	50-600	5
HKC-BS5	50-900	2.5
HKC-BT	50-600	15
HKC-E	50-500	12-15
HKC-EKA	100-500	15
HKC-EKAD1	30-600	15
HKC-EKAS12	100-500	12
HKC-EKASDA-2012	20	24
HKC-EKASY-2012	50-500	24
HKC-EKB	200-2000	15
HKC-EKBS12	200-2000	12
HKC-FK	200-1000	15
HKC-H	600-3000	15
HKC-HA	800-5000	12-15
HKC-HAHS52	50-1500	5
HKC-HAS	50-600	15
HKC-HASP	50-600	15
HKC-HAT	100-2000	15
HKC-HAX-2019	500-2500	15
HKC-HB-2019	1000-12000	15
HKC-HOP	800-3000	15
HKC-K	400-2000	15
HKC-KB-2019	800-3000	15
HKC-KB	500-5000	12-15
HKC-KC	1000-10000	15
HKC-LBP	200	15
HKC-LBS5	50-450	24
HKC-LTH	10-450	15
HKC-N	50-1000	15
HKC-PTPS	50-150	5
HKC1000SML	1000	15
HKC18P-D1	40-60	15
HKC18P-D15	40-60	15
HKC18P03-50D15	3-50	15
HKC2000F	200-2000	12-15
HKC2000H	600-3000	12-15
HKC2000K	400-2000	12-15
HKC200LBP-4V	200	15
HKC2105-20	50-500	12-15
HKC4000KB-170316	500-4000	12-15
HKC5000HOP-180108	2000-5000	15

FERRTX is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our Closed Loop Hall Effect Current Sensor HKC products.
