CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)
CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)
CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)
CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)
CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)
CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)
CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)

Video

1 / 7

CNC Automatic Hydraulic Round Bar Hoop Bender and Cutter (4-20mm)

$3000.00 ~ $14700.00 / set

Options:

  • RM4-10S
  • RM4-10
  • RM4-12
  • RM4-14
  • RM4-16
  • RM4-20
Get Latest Price

Basic Info

Model No.
Brand Name
Place of Origin Henan, China
Condition New
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type Hot Product 2023
Warranty of core components 1 years
Core components Bearing
Material / Metal Processed Aluminium Alloy, Aluminum, Alloy, Brass / Copper, Stainless Steel, Carbon Steel
Automation Automatic
Year 2023
Weight (KG) 2000
Key Selling Points High-Accuracy
Warranty 1 Year
Motor Power (kW) 18.2
Applicable Industries Retail, Farms, Construction works
Showroom Location None
product name Steel Bar Bending Straightening Cutting Machine
Application Metal Process
Single round bar diameter 4-14mm
Single screw bar diameter 4-12mm
Power consumption 5kw/h
CNC system PLC system
Weight 2 tons
bending angle 180°
Packing wooden box
Voltage 220V/380V/415V/440V/customized
Show More

Product description

Product Description

?

Automatic Rebar Stirrup Straightening Bending Hoop

Cutting Machine

?

Automatic stirrup bending machine CNC servo control system, can be done automatically reinforced straightening, cut to length, bending hoop, cutting and other process, the maximum diameter of 14mm can bend steel, continuous production of any planar shape of products. This product is widely used in railways, highways, bridges, airports, real estate, large steel bar processing plants and other fields.

?

?

?

Product Structure

?Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine

?

?

Product Details
?Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine

?

CNC Automatic Computer System

This machine adopts automatic numerical control system, which can process stirrups of various shapes.
?
Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine
?
Straightening The Traction System
The straightening equipment has high efficiency and good effect, and adopts two-wire automatic wire feeding.The rollers are made of wear-resistant special alloy steel.
?
Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine
?
Pneumatic Telescopic System
Hydraulic,mechanical cutting can be customized.Adjustable speed design,angle,precise bending hoop angle.
?
Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine

?

Internal Structure

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?Thick body, clear internal structure,easy to operate

?

?

Product Display

?Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine

?

Various Models

?

?

Model
ZH4-12
ZH4-16
Single-line processing capability
4-12mm
4-16mm
Dual-line? processing capability
4-8mm
4-12mm
Bending angle
180°
180°
Center pin diameter
16/18/20
16/18/20
Maximum traction speed
80-130m/min
80-130m/min
Maximum bending speed
1000/sec
1000/sec
Length accuracy
±1mm
±1mm
Average power consumption
3-5kw/h
3-5kw/h
Number of roots processed
≤2
≤2
Air pressure
≥-10-12
≥-10-12
machine power
18.2kw
52kw
Rebar processing shape
280 types
280 types
Gross weight
1680kg
2000kg
Host size
320*95*175cm
340*110*190cm
Product Applications

?Automatic Hydraulic Round Bar Hoop Bender And Cutter CNC 4-20MM Stirrup Hoop Bending and Cutting Machine

?
