Function:

This? computer control? tensile compression strength testing machine is suitable for metal materials, non-metal materials, composite materials, like metal wire, rebar, wood, cable, nylon, leather, tape, aluminum, alloy, paper, fiber, plastic, rubber, cardboard, yarn, spring etc..This testing machine can be equipped with different clamps, then it can test the tensile strength, compression strength, bending strength, bonding strength, tearing strength, breaking strength, yield strength, elongation rate, elastic modulus and so on.

?

Character:

This tensile compression welding strength testing machine?is computer controlled, electronic power loaded. During the testing process, the computer screen can display the test force, displacement, deformation and curve. After the test, you can save the test data and print the test report.

?

Customization:

About the Max. test force, test space, clamps, according to test material and testing requirement, you can customize the appropriate testing machine and clamps to satisfy your entire all your test needs.

?

Security:

For security, we install the inhibiting device and scram button. Besides when overload occurs, the testing machine will stop automatically.??

?

?Technical parameter:

?

Model	EWN-10KN	EWN-20KN	WN-50KN	EWN-100KN	EWN-200KN	EWN-300KN
Maximum test force(KN)	10	20	50	100	200	300
Precision grade	1 or 0.5?grade
Test force resolution(KN)	0.001	0.001	0.001	0.01	0.01	0.01
Test force display value resolution	1/500000
Testing force measuring range	1-100%F.S
Deformation range	1-100%F.S
Distortion value error	Within 1% or 0.5% of indicating value (depending?on the?machine?precision level)
Displacement indication error	Within 1% or 0.5% of indicating value (depending?on the?machine?precision level)
Displacement resolution	0.01mm
Effective tensile test space (mm)	650	650	650	650	620	620
Valid test width(mm)	400	400	400	400	600	600
Speed adjustment range	0.01-500mm/min,? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?0.01-300mm/min
Power Supply(V/Hz)	Single phase, AC220V/50HZ

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?

?
