Decoiler of Washer Drum Blanking Line
Basic Info
| Model No. | 7580 Washer Drum Line |
|---|---|
| Brand Name | IDO |
Product description
Decoiler of Drum Blanking Line
An auto paper winder is required.Pneumatic motor with pressure regulator is preferred.Paper break sensing is included.
The speed of decoiler is adjustable.
Maximum allowable vertical deflection withim 5mm with maximum load on the head and positioned in the centre of the mandrel.This is measured from the far end of the mandrel as per figure 2 showing below.
Project Description |
|
| Maximum Loading Capacity | 5000KG |
Internal Coil Diameter Range |
450-550MM |
Coil Widgh Range |
200-500MM |
Maximum Coil Outside Diameter |
1400MM |
Q: Are you a factory or trading company?
A: We are a factory which has been producing metal stamping moulds for more than 10 years.
A: Yes, of course. We can custom make for you based on your drawing or sample
Q: What are your main products?
A: We specialize in designing and manufacturing sheet metal stamping tools/moulds mostly for household appliance and automobile
industry, CNC machining parts and mould supporting facilities etc.
Q: How can I get the quotation?
A: Normally, we can get back to you within 24 hours when getting your detailed 3D drawing and requirements. If the project include
s many different parts, we will try our best to get back asap.In order to quote for you earlier, please provide us the following
information together with your inquiry.
1) 2D and 3D Drawings (DWG, STP, STEP, X_T, IGES, PDF)
2) Material requirement
3) Surface treatment requirement
4) Quantity (per order/per month/annual)
5) Any special demands or requirements, such as packing, labels,delivery,etc.
Q:What technical documentation do you supply?
A:
1)3D Format in STP
2)2D Format in DWG,2D need to be deliver printed as well
3)Parts list complete-compatible with cad data
4)Process map with dimension from the stamped out of every tool step
5)Final design update after final adjustment and final acceptance
6)All standard punching tool who was change must be add to the documentation
7)Manual with photos to explain how assenmbly and disassembly tool
Decoiler of Washer Drum Blanking Line
Send your inquiry to this supplier
You may also be interested in
Product Categories
$170000.00
1 Set/Sets (MOQ)
