Diesel Underground Haggloader for small mining operation
Model:
- Weight(kg) 14000
- UL50D
- Standard bucket(can be customized) (m3) 2.5
- Tramming Capacity(kg) 5000
- Max. turning angle(°) ±38
- Min. inner turning radius(mm) 2449
- Min. outer turning radius(mm) 4832
- Diesel engine output(kW) 97
- Max. breakout force(kN) 103
- Max. lifting force(kN) 77
- Max. dumping height(-40°dumping angle)(mm) 17
- Speed(km/h) 0-19.4
- Dimensions( W×H×L)(mm) 1770×2050×7227
Basic Info
| Model No. | UL50D |
|---|---|
| Brand Name | LGMRT |
| warranty period | 6 Months |
| Applicable industry | Energy &Amp; Mining, Construction Works, Machinery Repair Shops, Manufacturing Plant |
| Where to provide local services (in which countries are there overseas service outlets) | Argentina, Kenya, South Africa, Kazakhstan, Ukraine |
| Video factory inspection | Provided |
| Mechanical test report | Provided |
Product description
Lingong torque converter and power shift gearbox are adopted in the underground scooptram UL50D. No-spin antiskid differential is equiped in front drive axle to ensure it is safe to work in dire circustance like muddy place. Double support sewing hange is adopted in the rear axle to reduce failure rate. The bucket is designed to be V shape to reduce shovelling resistence. Working and parking brake using braking chontrolled by hydraulic system to ensure braking is reliable and safe.
EATURES
High safety
Safety canopy designed according to FOPS & ROPS safety standards;
POSI-STOP brake system ensures brake safety.
High reliability
Renowed and reliable key components are used;
Exceptional key performance management and lean product system.
Easy maintenance
Daily maintenance can be done on the ground level;
Central lubrication and pressure testing system.
PARAMETER
|
Model |
Bucket (m3) |
Capacity (t) |
Engine |
Torque Converter |
Transmission |
Axle(front/rear) |
Dimensions ( W×H×L)(mm) |
Weight (kg) |
|
UL50H |
2.5 |
5 |
Deutz 97kW |
DANA |
DANA |
LINGONG |
1790×2010×7135 |
13800 |
APPLICABLE INDUSTRIES
Underground Metal Mine
Tunnel construction
WORKING CASES
This equipment is limited to purchased by Chinese companies for overseas construction.
- 6yrs
- Distributor/Wholesaler
- Manufacturer
- Retailer
- Service
- OEM service
