Outdoor 576x576 Die Cast Cabinet Series P3 P4.8 P6, Digital Menu Board Systems Screens

Led Screen Advertising improved competitive price with better effect and quality. The Die Casting Aluminum Cabinet size is 576x576mm, Outdoor Led Screen Usage, Good Choice For Led Screen Display P3mm P4.8mm P6mm.

Led Screen Rental to achieve uniform brightness and driving chip of high consistency and pixel brightness consistency.The Led Screen showed more uniform and more clear. When choose 576mm x 576mm Led Screen Rental Cabinet, it can depend on different price for P6 P4.8 P3, because all their module size is 192x192mm, it is easy to make 576x576 Die Cast.

OUTDOOR FULL COLOR P3 P4.8 P6 LED DISPLAY SMD 3IN1
Unit Module of Led Screen Rental	Item	Parameter	Parameter	Parameter
	Model Number	HM-PH3-16S	HM-PH4.8-10S	HM-PH6-8S
	Module size	192mm*192mm	192mm*192mm	192mm*192mm
	Pixel pitch	3mm	4.8mm	6mm
	Pixels Density	111111dots/m2	43402dots/m2	27777dots/m2
	Pixel configuration	1RGB 3in1	1RGB 3in1	1RGB 3in1
	Package mode	SMD1921	SMD2727	SMD3535/2727
	Pixel resolution	64dots(W)*64dots(H)	40dots(W)*40dots(H)	32dots(W)*32dots(H)
	Drive type	Constant Current Drive	Constant Current Drive	Constant Current Drive
	Scan mode	1/16scan	1/10scan	1/8can
	Port type	HUB75	HUB75	HUB75
	Brightness of white balance	≥5000cd/m2	≥5500cd/m2	≥5500cd/m2
LED Screen Display Cabinet	Dimension	576mm*576mm	576mm*576mm	576mm*576mm
	Monomer Module Number	9pcs	9pcs	9pcs
	Pixel per cabinet	192dots*192dots	120dots*120dots	96dots*96dots
	Best viewing distance	3M~30M	5M~48M	6M~60M
	Best viewing angle	160°(W) 120°(H)	160°(W) 120°(H)	160°(W) 120°(H)
	Temperature	storage:-35oC~+85oC	storage:-35oC~+85oC	storage:-35oC~+85oC
		working:-20oC~+50oC	working:-20oC~+50oC	working:-20oC~+50oC
	Relative humidity	10%-95%	10%-95%	10%-95%
	Thickness	120mm	120mm	120mm
Power	Working voltage	AC220V±10%	AC220V±10%	AC220V±10%
	Average Power consumption	≤300W/m2	≤300W/m2	≤300W/m2
	Max.Power consumption	≤800W/m2	≤800W/m2	≤900W/m2
	Current	≤20mA(single LED)	≤20mA(single LED)	≤20mA(single LED)
Control System	CPU	Pentium4 or above	Pentium4 or above	Pentium4 or above
	Operation system	WIN98/2000/NT/XP/WIN7	WIN98/2000/NT/XP/WIN7	WIN98/2000/NT/XP/WIN7
	Control method	Synchronous and Asynchronous	Synchronous and Asynchronous	Synchronous and Asynchronous
Main Technical Parameter	Driving device	Constant drive IC	Constant drive IC	Constant drive IC
	Refresh frequency	≥1920HZ	≥1920HZ	≥1920HZ
	Grey scale/colors	65536gray level/16.7M colors	4096gray level/16.7M colors	4096gray level/16.7M colors
	MTBF	≥100000hours	≥100000hours	≥100000hours
	Power switch	Automatic switch	Automatic switch	Automatic switch
	Display Mode	≥800*600/1024*768	≥800*600/1024*768	≥800*600/1024*768

The more infomation of Jongsun LED Screen Display Products, we compare our Led Screen to Others, our grayscale, refresh rate and brightness is better.

When you buy our LED Display products, we have the following sevice to you.

Free Training: Via the internet, or in our workshop, we provide all the traing including process

                       of operation LED Display, installation, maintenance, system set up, repair etc.

Trade Terms:

1, Payment: T/T 30% Deposits, 70% Balance to be paid before leave factory.

2, By Air or Sea based on customer's needs.

3, Shipping port: Shenzhen, Guangzhou, Hongkong for choose.

4, MOQ: 1 piece.

FAQ:

Q1: What is the warranty for the led display?

A1: (1)Normally we will provide customers 1-2 years warranty and long term technology support and after-service.

       (2)After the completion of the LED Display project, we will conduct life maintenance of the system continuously

and update the and software.

       (3)For the hardware equipment, we only collect expenses on components. Customer bears the round-trip freight

Q2: How do you ensure the quality
A2: We get three QC processes:1.For raw materials;2.During the half of production; 3.Final QC test one by one after aging 24 hours.

Q3: How to do if any quality problems on our side in the warranty time?
A3: In usually every screen we will be ready more extra led screen modules as spare modules, if some modules happen fails, you can replace the fail modules by our spare modules,

When all the spare modules use out, You can send back these modules for us to repair, and we will send to you after repair and testing&aging well.

Q4: OEM OR ODM accepted?
A4:Yes,we can do OEM & ODM, logo on the PCB or package both are available.

Q5: Which refresh rate for the led display you can provide?
A5:the maximum refresh rate can be achieved more than 3840Hz. Also we can provide the normally refresh rate if you need.

Q6:  How many days will samples be finished?And how about the mass production?
A6: Generally 5-7 days for samples making. The leading time of mass production will depend on the quantity.
