Basic Info
| Model No. | Automatic Revolving Door |
|---|---|
| Brand Name | Ningbo GDoor |
| Material | Aluminum Alloy |
| Type | Revolving |
| Open Style | Revolving |
| Opening Type | Induced |
| Special Function | Security |
Product description
Disabled Access Function for Automatic Revolving Doors:
Disabled access function is one of the outstanding features of Ningbo GDoor automatic revolving doors. The low-speed button is used to control the speed of the door and slow down the speed for the security of the younger, the elderly and the disabled.
Ningbo KBB
Technical Data
1. Power supply : 220 VAC±10%, 50 HZ
2. Rated current :12 VAC, 50 HZ
3. Rated power : 600 W
4. Down lights : 400 W
5. High speed adjustment range(revolving door) : 1~4 r.p.m.
6. Low speed adjustment range(revolving door) : 0.5~1.5 r.p.m.
7. Ambient temperature : -30~45 degree
8. Max relative humidity : 90%.
9. Total weight : <1000 Kg
10. Operating noise : ≤ 60 db (A)
Security functions
1. Anti-squeeze
2.. Anti-strike
3.. Force-sensitive Control
4. Torque Control
5. Panic breakout system
6. Handicap
7. Night Security Door
8. Special Load-Bearing Structure
9. Vertical/horizontal safety switch
Operation features
1. Go/Stop working mode
2. Remote control function
3. Continuous working mode
