gate valve flanged

1 / 1

gate valve flanged

Get Latest Price

Basic Info

Model No. NRGV3246
Brand Name GALA

Product description

Specifications 1.Comply to DIN design.

2.DN50-600.

3.ISO9001&CE certificate.

4. PN10/16.

5.Soft seating body.

Introduction: Our company?is alibaba gold member for nine year.We have attend the large-scale exhibition at home and abroad each year.We are?professional valves manufacturer,factory located in Tianjin,?our mainly products for fire products, water works and HVAC.
The?products with ISO9001, CE, UL/FM approved. website:
? TECHNICAL DATA Valve Standard: DIN3352 ? Nominal diameter: 2"-24"/DN50–DN600 ? Working pressure: 10BAR/16Bar ? Face-to-face: DIN3352 F4 ISO5752 Series14 ? Flange accommodation: DIN 2501 PN10/16 ? Tightness check: API 598 ISO 5208, EN12226-2 ? Material Specification
Part Material EN Spec.
Body Ductile?iron/Cast iron EN-JL1050/EN-JS1040
Bonnet Ductile?iron/Cast iron EN-JL1050/EN-JL1040
Disc EPDM coated DI EN-JS1050
Stem Stainless steel BS970 420S37
Gasket NBR Commercial
Hand wheel Ductile iron En-JS1050
? ?Dimensions
DN mm 50 65 80 100 125 150 200 250 300 350 400 450 500 600
? inch 2 2-1/2 3 4 5 6 8 10 12 14 16 18 20 24
? L 150 170 180 190 200 210 230 250 270 290 310 330 350 390
? H 195 222 251 282 340 379 461 559 639 762 836 957 1036 1188
? D 160 200 200 200 250 250 320 370 370 450 450 640 640 640
? ?
