Overview:

GCK(L) type LV withdrawable switchgear cabinet can meet different need for power supply and distribution,according to the needs of system, it has functions of protection and control circuit.

The product is suitable for LV distribution system of AC 50HZ, rated voltage 380V, rated current up to 3150A,as incoming, feeding, lighting , control of motors.It includes functions between power center (PC) and motor control center(MCC),designed to fixed cabinet and mixed type drawer system, to meet different needs of power supply and distribution.

In the PC program, has functions such as power reception, bus coupler circuits, power feeding while the electric current is under 3150A . Main switches are from domestic SEW1/AH/ME, F/E series of imported ABB switches, MT series of MEG switches. Easily operated and safety.

In the MCC program, has functions such as power feeding, lighting, motor controlling and reactive compensation while the electric current is under 630A . Select domestic SEM1, DZ20, Q series and imported ABB and MEG switches to be main switches.

Main Characteristics:

1,Easy installation,beautiful appearance,various structure,easy maintenance.

2,Application range: power plants, oil, chemical,high rise building and textile industry etc.

3,Structure:Fixed board.

4,Operation voltage: Low voltage.

5,Shell material: Steel plate

6,Shell protection grade:IP30-40 or according to request

7,Form:All-packaged type
