GPPS diffusion panel production line
Diffusion panel is applicable to direct type and side type light source LED lighting.
Direct type light source led light, like downlights, grille lights, high grade aluminum lights.
Side type light source led light, like flat panel lights, advertising light boxes, professional film viewer, usually used with light guide panel.
Main technical parameters:

main extruder model	120/36	130/38
main driving motor power	185kw	250kw
Co-extruder model	45/33	45/33
Co-extruder driving motor	22kw	22kw
Sheet width	1000mm	1220-2100mm
Sheet thickness	0.3-3mm	0.2-2mm
Max output	450kg/h	600kg/h

Production flows:
dehumidifying drying system→SJ-100/36 single screw extruder→SJ-45/33 single screw co-extruder→hydraulic exchaning unit→T-type die head→three roller calendars→double position potective film coating machine→edge cutting units and haul off machine→plastic saw cutting machine→belt conveyor
Sheet Specifications:

1	Sheet width	650mm
2	Sheet thickness	1-4mm
3	Type	GPPS single layer or GPPS and PMMA co-extrusion layers
4	Raw material	GPPS, PS, PMMA
SHEET APPLICATIONS
1	flat panel lights, advertising light boxes, professional film viewer,
2	usually used with light guide panel.
PAYMENT, DELIVERY AND AFTER SALE SERVICES
1	Payment terms	40% for prepayment by T/T, 60% for balanced payment by T/T, or L/C can be acceptable
2	Delivery time	80 days after receipt of prepayment
3	Packing method	Wooden cases/pallets with stretching films
4	Guaranteed time	18 months for mechanical parts, 12 months for electrical parts
5	After sale service	Send 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable
6	Contact	Ms Lilly Zhou

Detailed images:

1. dehumidifying drying system

2. Extruders and hydraulic exchanger

3. Three roller calendars:

electrical parts:

samples

Company information:

contact information:
