High Performance Linear Modules

1 / 1

High Performance Linear Modules

Get Latest Price

Basic Info

Model No. C170
Brand Name

Product description

The fully enclosed linear module sliding table is mainly composed of aluminum body, diagonal bearing fixing seat, cover plate, sliding seat and other components. High-precision linear guide pair, aluminum alloy moving seat is installed on the slider, the middle of the moving seat is connected with the nut of the ball screw, the motor drives the sliding seat to reciprocate through the screw, and the diagonal bearing fixed seat can ensure the repeatability of the moving seat. With the positioning accuracy, the flexible stainless steel belt is sealed on the movable seat, and the whole can meet the requirements of dust-free grade.

C series adopts lead screw, high transmission repeatability, repeatability of rolling lead screw: ±0.01, and repeatability of grinding lead screw: ±0.005.Guangdong TICO is a high-tech enterprise specializing in R&D, manufacturing, sales and service of Slide Module, Linear Module, Linear Motion Unit, Precision Manipulator and Servo Positioning Slide automation equipment. The company has a number of long-term engaged in the field of automation control, not only rich field experience, but also hold the leading scientific and technological elite.


High Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear ModulesHigh Performance Linear Modules

Company Overview
Guangdong TICO is a high-tech enterprise specializing in R&D, manufacturing, sales and service of slide module, linear module, linear motion unit, precision manipulator and servo positioning slide automation equipment. The company has a number of long-term engaged i
