Type: Linear Array

Array elements: 128

?Scanning Geometry: L38.4mm

-6dB Center Freq.: 6MHz±10%

-6dB RBW: ≥80%

Sensitivity: >-60dB

Pitch: 0.3mm

Kerf: 0.02mm

Array Width: 0.28mm

Transverse Aperture: 4mm

Focal Length: 40

Plug: QLC260P is the default model, can be changed according to customer requirements.

Customer-Supplied Material: Pin Map of the host plug; other specifications (like host plug circuit board, ID, shell, sheath, nameplate, etc.) are subject to customer requirements.
