Inventory Mode 2D Codes Reader Wireless Barcode Scanner

$45.00

≥1 Others
$35.00

≥50 Others
$28.00

≥200 Others

Options:

WNI-S214

Get Latest Price

Basic Info

Model No.	WNI-S214
Brand Name	winson
Certification	Ce
product status	Stock
Types of	Barcode Scanner
Scanning element type	Ccd, Cmos
Color point	32 Bit
Interface Type	Usb
place of origin	China
Warranty period (years)	1-Year
After-sales service	Return And Replacement
Private Mold	Yes
Products Status	Stock
Type	Barcode Scanner
Scan Element Type	Cmos
Colour Depth	32 Bit
Interface Type	Usb, Rs232
Max Paper Size	N/A
Optical Resolution	640X480 pixels
Scan Speed	350 ±50 scans/second
Brand Name	Winson
Place Of Origin	Guangdong, China
Warranty(Year)	1-Year
After-sales Service	Call Center And On-Line Technical Support
Software development kit (SDK)	NO
Color	Blue, Black
Product Type	QR Code Scanner
Interface	USB HID KEYBOARD/USB VCP
Photo sensor	CMOS array sensor
Voltage requirement	DC5V±10%
Dimensions	90mm67mm168mm
Weight	130g
Indicator	Beeper, LED

Product description

Winson WNI-S214 Portable Wireless 2D Barcode Scanner 2.4G/BT Rugged scanner

Free Pos Software Read barcode as small as 3.3 mill.

General Purpose Scanners Support to put prefix or suffix before or after scanned data,turn on/ off buzzer, identity barcode type, add keyboard keys (TAB, CR&LF, etc.)

Cable Barcode Scanner Application fields:Supermarket, Retail, Warehouse,Logistic,Library, Medical etc.

Product Description

barcode scanner

winson company

Product Detail

Wireless Characteristics
Communication mode	Cache mode/Inventory mode
Communication mode	2.402 to 2.480GHz
Transmission range	30m(In empty area)
Battery capacity	2000mAh (Lithium battery)
Charge Time from Empty to Full Charge	5H
Duration of use	11H (wireless mode,real-time mode communication mode,60 scans/minute)

Electrical Characteristics
Interface Supported	USB HID KEYBOARD/USB VCP or RS-232
Input Voltage	DC 5V
Current	150mA
Performance Characteristics
Sensor	640×480 CMOS
Illumination	White LED
Focus	Red LED
Scanning Angle	Pitch angle:+55°
	Skew angle:+360°
	Tilt angle:+55°
Field of view	36°(H),27°(V)
Reading accuracy	≥5mil
Decode Capability	1D:Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar 2D:QR Code,Data Matrix,PDF417
Environmental Characteristics
Temperature	operation:-20°C to 60°C
	storage:-40°C to 80°C
Humidity	operation:5%~95% (no condensation)
Ambient light	0~100,000LUX
Decoding Depth of Field
Symbology	Resolution	Barcode number	Barcode width
Code128	13mil	10	4.3x3.1cm
Code39	5mil	7	3.5x1.19cm
EAN13	13mil	13	4.5x2.69cm
QR Code	15mil	30	1.9x1.85cm
Data Marix	10mil	30	4.5x1.16cm
PDF 417	6.67mil	30	4.0x10.5cm
