M3-M8 DIN 967 Cross Recessed Pan Head Screws With Collar Cross Recessed Pan Head Screws
$0.02
≥1000 Piece/Pieces
Types:
- Cross Recessed Screws
Length:
- 90mm
- 100mm
- 70mm
- 55mm
- 120mm
Thread size:
- 4 1/4"
- M3
- M10
- M12
- M8
1000 Piece/Pieces (MOQ)
Basic Info
| Model No. | DIN967 |
|---|---|
| Brand Name | ZG |
| Material | Stainless Steel |
| Standard | DIN |
Product description
Stainless Steel Cross Recessed Pan Head Screws with Collar DIN967
BOLTS: hex bolts, heavy hex bolts, hex flange bolts, carriage bolts, wheel bolts, stud bolts, square head bolts, T bolts, eye bolts, U bolts, hook bolts
NUTS: hex nuts, heavy hex nuts, hex flange nuts, nylon insert lock nuts, cap nuts, slotted nuts, rivet nut
WASHERS: flat washers, spring washers, lock washers
SCREWS: machine screws, self tapping screws, set screws, hex socket head cap screws, wood
screws, self drilling screws
?
?
| d | P | dc | k | h?? | Slot number | |||
| max | min | max | min | max | min | |||
| M3 | 0.5 | 7.5 | 6.92 | 2.35 | 2.1 | 0.8 | 0.6 | 2# |
| M3.5 | 0.6 | 9 | 8.42 | 2.6 | 2.35 | 0.9 | 0.7 | 2# |
| M4 | 0.7 | 10 | 9.42 | 3.05 | 2.75 | 1.1 | 0.9 | |
| M5 | 0.8 | 11.5 | 10.8 | 3.55 | 3.25 | 1.35 | 1.05 | |
| M6 | 1 | 14.5 | 13.8 | 4.55 | 4.25 | 1.8 | 1.4 | 3# |
| M8 | 1.25 | 19 | 18.16 | 5.9 | 5.6 | 2.2 | 1.8 | 4# |
?
?
?
Kunshan Zhonggu Precision Hardware Co., Ltd founded in 2006, is a set design, development, production, sale as a whole, professional production and operation of various types of industrial fasteners. View More
