Marble Engraving CNC Router Machines
Basic Info
| Model No. | 1325 |
|---|---|
| Brand Name | XUANLIN |
Product description
Marble Engraving CNC Router Machines
XUANLIN CNC routers is dedicated to providing the industry’s best CNC stone engraver tool support and committed to working with you to create the most innovative solution for your production needs.
With XUANLIN CNC machinery available at the Jinan city, Shandong province headquarters, our applications experts can demonstrate production of your exact parts. The creation and execution of programs, loading tools, holding parts and assembling completed units can all be performed in our Demonstration Room. We also maintain an inventory of materials from wood to metal to plastics and composites, with which we can demonstrate the diverse applications of XUANLIN CNC machines. Our CNC machines include the following types ,such as woodworking machine, lathe machine, cnc router for wood, 4 axis cnc, cnc 5 axis router, foam cutting machine, milling cnc machine . You see our machines can match your usages in almost all industrial.
Impressions
Technical Parameter
|
Description & Specifications: |
|
|
X Working Area |
1300mm |
|
Y Working Area |
2500mm |
|
Z Working Area |
200mm |
|
Traveling Positioning Accuracy |
±0.05mm |
|
Repositioning Positioning Accuracy |
±0.05mm |
|
Table Surface |
Aluminum with T slot and loading wheel |
|
X,Y ,Z Structure |
XY gear wheel, Z ball screw |
|
Max. Power Consumption(Without spindle) |
1.84KW |
|
Max. Rapid Travel Rate |
25000mm/min |
|
Max. Working Speed |
15000mm/min |
|
Spindle Power Motor |
5.5kw water cooling spindle |
|
Spindle Speed |
0-18000r/min |
|
Drive Motor |
servo motor and driver |
|
Command |
G-code*.u00*.mmg*.plt |
|
Working voltage |
AC380V/50Hz |
|
Control System |
DSP Control system |
|
Guide rail |
25 Square rail (TAIWAN BRAND:TBI) |
|
Control cabinet |
Big size Independent cabinet |
|
Software |
Wentai/type3/JD software |
|
Variable-frequency drive(inverter) |
FL- 7.5 KW |
Application
This series of models are mainly used for heavy weight of the tile, bluestone,marble, granite, white marble, sandstone,such as a stone sculpture processing, category carved glass-cutting and engraving melting material.
Marble Engraving CNC Router Machines
