Multi Function Automatic Flow Wrapping Machine
Basic Info
| Model No. | DZB-400D |
|---|---|
| Brand Name | Sanhuan |
Product description
Multi Function Automatic Flow Wrapping Machine
Pillow Packing Machine is suitable for packing biscuit, cookie, candy and so on pillow-type with various laminated film materials.
Pillow Packing Machine has been fitted with an automatic feeder which is suitable for AL-plastic tablet of various specifications. And an automatic edge-folder has been designed first of all, which can proceed edge-fold packing of materials with certain thickness.
Features:
*Variable frequency speed regulation of main motor: The main motor adopts imported frequency Converter to regulate speed, thus making it be suitable for all kinds of packing materials.
*Programmable control: It adopts PLC programmable controller to make running of the whole machine programmed.
*Electronic text display: The information of the speed of machine, the set bag-length and the actual bag length and the packing output will be clearly displayed on the screen of the TD-200 display.
Pillow Packing Machine is specially developed and manufactured by our scientific research personnel for a second packing of al-plastic drug plate in the pharmaceutical industry, thus upgrading the damp proof performance of the packed al-plastic drug plate and keeping the drug away from light. This machine adopts PLC programmable controller to program operation of the whole machine and it is equipped with number printing lot No. Of production, production Date and Term of Validity, etc. On the outer package during packing process.
*Main Technical Datas:
Production Capacity
30-100 Bags/min
Packing Size
L80-180mm, W30-180mm, H5-55mm(Can be sepcially designed)
Rated Frequency
50Hz
Rated Power Supply
AC220V
Total Power
2Kw
Weight
750kg
Overall Dimernsion
L*W*H 3900*1000*1400mm
Multi Function Automatic Flow Wrapping Machine
