Technical specifications

~Standard IEC60947-5-1

~Approval CE

~Rated insulation voltage Ui(V) 400

~Conventional thermal current lth(A) 10

~Rated operational voltage Ue(V) 110, 230, 400

~Rated operational voltageUe(V)

In AC-15 2.5 for 400V, 4.5 for 230 V

In DC-13 0.3 for 230V, 0.6 for 110V

~Rated frequency)(Hz) 50~60

~Electrical life(10⁵ times)

50 for flush-headed and mushroom-head type

10 for other types

~Mechanical life(10⁵ times)

10 for flush-headed and mushroom-head type

3 for button with light

1 for other types

~Degree of protection IP40

~Pollution degree 3

~Overvoltage category II

~Ambient temperature(℃) -5 to +40, max. 95% humidity

~Storage temperature(℃) -30~+65

~Maximum operating altitude(meters 2000
