Stainless steel wire mesh grid

Stainless steel wire mesh grid also named Stainless steel wire mesh cloth, filter wire mesh Stainless steel screen.Material: Stainless steel wire 201,202,304,304L, 316,316L, 321, 430, etc. used in filtering liquid, gas and pulp , The opening can be square, rectangular or special opening. Normally, this kind of wire mesh has standard opening sizes, uniform opening, good permeability and high strength , The raw material should be chosen according to different environment of application.

(2) Weaving pattern of Stainless steel wire mesh grid

Plain weave, twill weave, Dutch plain weave or Dutch twill weave.
Plain weave can be woven from 1X1mesh to 635X635 mesh
Plain Dutch weave can be woven perfect from 10X64mesh to 80X800mesh
Twill weave can be woven from 20x250mesh to500X3500mesh

(3) Technique of Stainless steel wire mesh grid

stainless steel wire diameter can from: 0.018-6mm, Min Aperture: 1 micron, Mesh count: 1-2800, Width:  3`, 4`, 5` etc. can up to 6m

 (4) Application of Stainless steel wire mesh grid

Sifting mesh used for industries of mining, oil, chemicals, food, pharmaceuticals, machine making, scientific research, aviation, filter & sifting gas, liquid, etc.

(5)  Stainless steel wire mesh grid  Packing:

Inside the roll with "paper tube" to reduce the pressure while loading; then wrapped with "plastic film" as well as the "woven bag" on the finished roll, final loaded in the strong wooden case or as customers' requirement.
