Two-component Silicone potting compounds

Video

1 / 4

Two-component Silicone potting compounds

Get Latest Price

You might also like

Two-component potting adhesive 10:1 mixing

1 Piece/Pieces (MOQ)

TWO-component silicone potting glue

1 Piece/Pieces (MOQ)

Two-component Silicone potting compounds

1 Kilogram (MOQ)

Basic Info

Model No.	SN-5610
Brand Name	LINGWO
place of origin	China
classification	Double Components Adhesives
main ingredient	Silicone
Application field	Construction, Fiber &Amp; Garment, Footwear &Amp; Leather, Packing, Transportation, Woodworking

Product description

Product introduction

LINGWO SN-5610 Silicone glue is a silicone potting glue in the silicone glue category. As sealing glue is a two-component, it can cure in the room temperature or heat curing.It is called electronic potting glue, it is commoned in bonding,sealing,potting,coating protection of electronic componnets.This product has the low viscosity, has good fluidity,after curing has good thermal conductivity and insulation.No corrosion for various substrates,Comply with EU standards.

Other attributes

? Place of origin	?Dongguan China
? Main raw material?	? Silicone
? State	? liquid??
? Brand Name	?LINGWO?
? Model Number?	?SN-5610
? Appearance	?A: white ?B: white
?Viscosity (CPs,25°C)	?A: 3000-4000 ?B: 3000-4000
?Mixing viscosity (25°C)?	?3000-4000
?Opening time (Min), 25°C	?10 Min
?Initial curing time ,25°C	?1H
?Fully curing time ,25°C?	?1.5H
?Mixing ratio(25°C)	?1:1
?Hardness (Shore A)	?30-40? A
?Tensile strength(Mpa)	?1Mpa
?Breaking elongation (%)?	?50%
?Thermal conductivity ,W/m·K	?0.9W/m·K
?Flame retardant. UL94	?V0

Product characteristics

1. Low specific gravity, high thermal conductivity.

2. Low viscosity, good fluidity, rapid degassing.

3. Excellent insulation performance,proof-water adhesive.

4. Curing at room temperature, heating can speed up the curing speed, no corrosion to the substrate.

5. Passed U certification.

Main application

1. Potting protection of power modules, power batteries, inverters, ballasts;

2. Potting protection of electronic control units and sensors:

3. Potting protection of LED lighting components;

4. Heat dissipation, insulation, moisture resistance, shock absorption and other uses of other electronic components.

Direction for use

(1) Weighing and mixing glue: Weigh components A and B in a 1:1 ratio (before applying glue, mix components A and B in their respective packaging evenly, because the fillers in the glue may partially settle during storage.)

(2) Mixing evenly: After mixing the glue, stir it with a metal stirring rod until it is evenly mixed.

(3) Replace container: Replace the container and let it stand or vacuum to remove bubbles.

(4) Glue filling: Inject the glue directly into the components (or modules) to be potted and protected. It is best to inject slowly along one side of the wall to reduce the generation of bubbles.

FAQ

Q1: Are you trading company or manufacturer?

A1: We are factory with 13+ years of experience,and can provide you direct prices.

Q2: Can I be your agent?

A2: Sure,we are looking for agent all over the world.

Q3: Can I get a sample before mass production?

A3: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q4: What can I buy from you?

A4: We are a manufacturer of industrial adhesive products,the main products are: Epoxy adhesive, liquid PUR, hot melt adhesive, UV adhesive, instant adhesive, acrylic structural adhesive, treatment agent, etc.

Q5: How can we guarantee quality?

A5: Always a pre-production sample before mass production;always final inspection before shipment.

Q6: Why should you buy from us not from other suppliers?

A6: Factory prices,on-time deliveries,assured quality,good service,before and after sales.
