Type Load Cell S Type Load Cell 500kg
Basic Info
| Model No. | LP130 |
|---|---|
| Brand Name | XG |
| place of origin | China |
| Series | LP |
| Features | High precision aluminum sensor |
| Mounting Type | Single point weighing sensor |
| Description | Single point weighing sensor, loadcells |
Product description
Type Load Cell S Type Load Cell 500kg
Product Description
The S type load cell is a type of force transducer that is designed to measure tensile or compressive loads with high accuracy. It is called an S-type load cell because of the shape of the load cell, which resembles the letter S. The load cell has two threaded holes, one for attaching the load to be measured and the other for attaching the device that will measure the load.
The S-type load cell has a nominal capacity of 500kg, which means that it is capable of measuring loads up to 500kg. This load cell is commonly used in industrial weighing applications such as platform scales, hopper scales, and crane scales. It is also used in force measurement applications such as material testing machines and tensile testing machines.
The load cell is made of high-quality materials like stainless steel, which makes it resistant to corrosion and ensures long-lasting performance. It is also designed to be compact and easy to install, which makes it ideal for use in a wide range of applications. The load cell comes with a calibration certificate, which ensures that it is accurate and meets the required standards.
Product Specification
Output:
2.0vm/v
Name:
Load cell
Model number:
LP130
Capacity:
3~120kg
Rated Output:
2.0±0.2
Non-linearity:
0.03%FS
Hysteresis:
0.03%FS
Repeatability:
0.03%FS
Zero balance:
0.03%FS
Input impedance:
405±6Ω
Output impedance:
350±5Ω
|
Specifications
|
||
|
Rated Output
|
mv/v
|
2.0±0.2
|
|
Non-linearity
|
%F.S
|
0.03%F.S
|
|
Hysteresis
|
%F.S
|
0.03
|
|
Repeatability
|
%F.S
|
0.03
|
|
Creep
|
%F.S/3min
|
0.03
|
|
Temp.effect on zero
|
%F.S/10℃
|
0.03%F.S
|
|
Temp.effect on span
|
%F.S/10℃
|
0.05%F.S
|
|
Zero balance
|
mv/v
|
±0.05
|
|
Input impedance
|
Ω
|
405±6
|
|
Output impedance
|
Ω
|
350±5
|
|
Insulation resistance
|
MΩ
|
≥2000（100VDC)
|
|
Recommended excitation voltage
|
VDC
|
3~12
|
|
Allowed excitation voltage
|
VDC
|
3~12
|
|
Compensated temp.Range
|
℃
|
-10℃~+40℃
|
|
Operating temp.Range
|
℃
|
0℃~+40℃
|
|
Safe overload
|
%F.S
|
120
|
|
Ultimate Overload
|
%F.S
|
150
|
|
Connection
|
Excitation: Red:+ Black:-
|
|
|
Signal: Green:+ White:-
|
||
|
|
|
|
Type Load Cell S Type Load Cell 500kg
