Basic Info

Model No.	TRJBQ3L
Brand Name	TR

Product description

TR solid control provide vertical and horizontal agitator.Vertical agitator are divided into axis-and direct-connected blender.Vertical Agitator is used for mixing, mixing liquids and prevent the mixture of solid phase precipitation`s ideal device.

The gearbox adopted worm and gear. Better scuffing more reliable.
Motor and gear box will be connected by coupling or directly. Agitation speed is more stable.
Good heat exchange performance faster cooling down.
Lower decibels.
Shaft and blades are customizable.
Durable enough, easy to install, operate ,and maintain.
Can be used under variety condition.

Mud Agitator Parameter

Model	TRJBQ3L	TRJBQ5.5L	TRJBQ7.5L	TRJBQ11L
Moter	3kW(4hp)	5.5kW(7.5hp)	7.5kW(10hp)	11kW(15hp)
Impeller Speed	58/72rpm	58/72rpm	58/72rpm	58/72rpm
Single Impeller	850mm	950mm	1050mm	1150mm
2 Layer Impeller	N/A	Higher:850mm Lower:750mm	Higher:900mm Lower:800mm	Higher:950mm Lower:850mm
Ratio	25:1	25:1	25:1	25:1
Dimension	400x400x750	500x500x800	500x500x830	550x550x950
Weight	160kg	190kg	240kg	290kg
Shaft Length	According to tank internal height
Frequency	380V/50HZ or 460V/60HZ or Customizabel
Remark	Explosion proof motor, shaft stabilizer optional.
