USB to PC joystick arcade encoder board Jamma keyboard for emulations

I. Overview: This single-chip is a multi-function USB joystick control chip (4-axis 12-button 1POV) controller, this circuit is compatible with USB1.0/USB2.0 and supports Win98 / Win Me / Win 2000 / Win XP, Passed USB Check and Hid View Tests. 4-axis 12KEY 1POV default interface form in Windows:

Second, characteristics

High-performance COMS technology.

The joystick IC supports a variety of game device formats, and can be freely converted in Digital, Analog mode in both device formats.

The function keys TURBO and AUTO modes are supported with LED flashing.

USB Connect Good Instructions.

Supports 8-bit ADC for 3D joystick and 7-bit PWM for ANALOG.

Support center point positioning and dead center function of the power axis.

Supports the above versions and supports all ForceBack games that support DirectX Output in Win2003 and the following operating systems.

Third, the functional description

AUTO-FIRE mode: When the function key is pressed simultaneously with the AUTO key, the function key enters the AUTO-FIRE mode, and the corresponding DLED or ALED flashes at a frequency of 12 Hz. When the key is pressed simultaneously with the CLR key, it exits the AUTO-FIRE mode, and the DLED or ALED returns to the steady-on state.

?TURBO mode: If the function button is pressed simultaneously with the TURBO button, the function button enters TURBO mode. Pressing the function key in this mode will cause the corresponding DLED or ALED to flash at 12 Hz. If not pressed, the DLED or ALED will remain on. When this function key is pressed simultaneously with the CLR key, the TURBO function is cleared.
