TFT LCD panel: How to properly use and keep the TFT LCD panel?

1. After the user receives the TFT LCD screen product acceptance, if the product package is found to be obviously damaged or other quality problems, please keep the product in good condition and take pictures, and contact the manufacturer in time Thin Film Transistor;

2. When the TFT LCD screen is transported, stored and used, the TFT screen must be controlled within the allowable temperature range, kept at a humidity of 40% to 60%, and stored in a dust-free environment;

3. When using the TFT LCD screen, AC power is not allowed, and the maximum DC component must not exceed 50mV. LCM only solders the I/O interface when soldering, the temperature of the soldering iron does not exceed 260 degrees, and the soldering iron is used for no more than 4 seconds after soldering. Pay attention to clean the stains on the PCB board after soldering;

4. When LCM is assembled, the operator should wear anti-static gloves and anti-static clothing. The soldering iron and other appliances should be well grounded, and the surface of the TFT screen should be protected during soldering to prevent the flux from splashing on the surface and causing damage;

5. The equipment should not be exposed to direct sunlight and ultraviolet rays for a long time, so as not to affect the service life TFT LCD Display;

6. Do not stain the TFT LCD screen with organic solvents; when installing, avoid hard objects and top damage, and do not touch grease or oil TFT LCD module.
