Resolution

4,6,8,10,12 Division

Output Logic

Positive Logic

Output Code

Pure Binary

Supply Voltage

DC24V±5%

V_H Output Voltage

≥Vcc*70%

V_L Output Voltage

≤0.5V

Current Consumption

≤60mA

Frequency Response

5kHz Max

Rise / Fall Time

-

Injection Current

≤50mA

Measurement Range

0~360°

Measurement Error

±20”

Starting Torque

1.5*10^-3N*m(+25℃)

Shaft Loading

Radial

20N

Axial

10N

Rotating Inertia

2*10^-7Kg*m²

Max Rotating Speed

180r/min

Vibration Resistance

50m/s²(10~200Hz)2 Hours in xyz Direction

Shock Resistance

980m/s^{2 ??}3 Times in xyz Direction,continue 6 mS

Protection

IP65

Operating Temperature

-10℃~+70℃

Storage Temperature

-20℃~+80℃

Operating Humidity

30~85%RH

Weight(no cable)

Around ?0.2Kg

Accessories

SE/PE Coupling

Cable Color

Red

Black

Brown

White

Green

Yellow

Blue

Pink

Shield

Signal

DC 24V

0V

TP

2⁰

2¹

2²

2³

EP

FG

Station

1

2

3

4

5

6

7

8

9

10

11

12

Output Signal

?

?

?

?

?

TP

1

1

1

1

1

1

1

1

1

1

1

1

2⁰

1

0

1

0

1

0

1

0

1

0

1

0

2¹

0

1

1

0

0

1

1

0

0

1

1

0

2²

0

0

0

1

1

1

1

0

0

0

0

1

2³

0

0

0

0

0

0

0

1

1

1

1

1

EP

1

1

0

1

0

0

1

1

0

0

1

0
