Scanning Hand held bar code reader Barcode Scanner

$29.00

≥1 Others
$25.00

≥50 Others
$23.00

≥200 Others

Options:

WNC-5060g

Get Latest Price

Most Popular barcode scanner WST-9760HD

Pos scanner supermarket money check logistic parking

Scanning Hand held bar code reader Barcode Scanner

2D Barcode Scanner Handheld Scanner Gun

CMOS 2D Wireless 2.4G Reader

Basic Info

Model No.	WNC-5060g
Brand Name	winson
Certification	Ce, Other
product status	Stock
Types of	Barcode Scanner
Scanning element type	Ccd
Color point	32 Bit
Interface Type	Usb
place of origin	China
Warranty period (years)	1-Year
After-sales service	Call Center And On-Line Technical Support
Products Status	Stock
Type	Wireless 1D Scanner
Scan Element Type	CCD Barcode Scanner
Colour Depth	32 Bit
Interface Type	usb, COM, PS/2
Max Paper Size	N/A
Optical Resolution	1500 pix
Scan Speed	350+50(scans/second)
Brand Name	Winson
Place Of Origin	Guangdong, China
Warranty(Year)	1-Year
After-sales Service	Call Center And On-Line Technical Support
Product Name	Wireless 1D Scanner
Product Type	1D CCD Barcode Scanner
Photo sensor	CCD linear sensor
Communications	Wired transmission mode
Communication frequency	BT 4.0
Voltage requirement	5VDC±10%
Print Contrast	20%UPC/EAN 13(13mil)
Current	Max:135mA
Light Source	632nm red LED
Dimensions	90mm67mm168mm

Product description

Barcode Scanner

2d Cmos Barcode Scanner Application fields: parcel locker,supermarket locker, ticket machine, self-service vending machine, intelligent express cabinet, kiosk,locker, access control machine,self-service store, check-in machine, bank counter machine, factory assembly line,logistics, hospital,PDA,etc.

Fast Scanning Black White Hand held bar code reader 1D laser usb wried barcode Barcode Scanner Module

Support secondary development -- the serial port development instruction is complete to satisfy each kind of host computer control interactive demand.

With mini USB receiver, plug and play, Ergonomic design, comfortable to hold Qr Scanner Module.

Barcode Scanner

winson company

Product Detail

Technical Specifications
Wireless specifications
Communication mode		Wired transmission mode/ Wireless Read-time mode&Inventory mode/Cache mode
Communication frequency		BT 4.0(2.402 to 2.480GHz Adaptive frequency hopping)
Transmission range		≤10M(In empty area 15M)
Battery capacity		1500mAh (Lithium battery)
Charge Time from Empty to Full Charge		4.5H
Scans per Battery Charge		30,000 (1 scan per second)
Memory		100,000@13Byte barcode
Electrical Characteristics
Interface Supported	USB HID KEYBOARD
Input Voltage	DC 5V±10%
Current	Max:135mA
Optical Characteristics
Image Sensor	CCD Linear Sensor
Sensor Resolution	2500pixels
Light Source	632nm Red LED
Performance Characteristics
Decoding rate:	350 scans/second±20 scans/second
Scanning Angle	Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40°
Min Resolution	0.105/4mil(PCS 0.9)
Min .PCS value	>25%UPC/EAN 13(13mil)
Language	Multiple Languages
Data Edition	Support for custom data output
Decode Capability	EAN13,EAN8,UPC A,UPC E,CODABAR(NW-7),CODE 39,CODE 93,INTERLEAVED 2OF5,STANDARD 2OF5,MATRIX 2OF5,CODE 128,EAN/UCC 128,CODE 11,CHINESE POST
Physical Characteristics
Dimensions	Scanner:90mm67mm168mm(LWH)
Weight	Scanner:160g
Indicator	Beeper, LED
Environmental Characteristics
Temperature	-20° to 65°C / -4° to 149°F(operation) /-30° to 70°C /-22° to 158°F(storage)
Humidity	5 - 90% (operation) ) 5 - 90% (storage)
Ambient Light:	Up to 80,000 lx
Shock Drop Test	1.5m drop onto concrete surface
