vision scanner Barcode Reader

Options:

Get Latest Price

Basic Info

Model No.	WNC-9090
Brand Name	winson
Certification	Ce
product status	Stock
Types of	Barcode Scanner
Scanning element type	Ccd, Cmos
Color point	32 Bit
Interface Type	Usb
place of origin	China
Warranty period (years)	1-Year
After-sales service	Call Center And On-Line Technical Support
Private Mold	Yes
Products Status	Stock
Type	Barcode Scanner
Scan Element Type	Ccd
Colour Depth	32 Bit
Interface Type	Usb, Rs232
Max Paper Size	N/A
Optical Resolution	2500pixels
Scan Speed	350±50 (scans/second)
Brand Name	350±50 (scans/second)
Place Of Origin	Guangdong, China
Warranty(Year)	1-Year
After-sales Service	Call Center And On-Line Technical Support
Software development kit (SDK)	NO
Color	White
Product Type	1D Wired Barcode Scanner
Input Voltage	DC 5V±10%
Current	Max:105mA
Image Sensor	CCD Linear Sensor
Min .PCS value	>30%UPC/EAN 13(13mil)
Interface	RS-232/USB
Light Source	632nm red LED
Certification	Ce

Product description

Easily handling barcodes in bulk

General Purpose Barcode Scanner winson factory price barcode reader ce rohs certification cmos scanner for supermarket/store

Product Description

Specification

Interface Supported	RS-232/USB HID KEYBOARD/USB VCP
Input Voltage	DC 5V±10%
Current	Max:105mA
Image Sensor	CCD Linear Sensor
Sensor Resolution	2500pixels
Light Source	632nm Red LED
Decoding rate:	350 scans/second±50 scans/second
Scanning Angle	Pitch angle:±70°;Skew angle:±70°;Tilt angle:±45°
Min Resolution	≥0.076mm/3mil（PCS 0.9）
Min .PCS value	〉20%UPC/EAN 13（13mil）
Language	Language
Data Edition	Support for custom data output
Decode Capability	EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, PlesseyEAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey
Dimensions	55.3mm47.7mm187mm(LWH)
Indicator	Beeper, LED
Temperature	0°∽50°C / 32°∽122°F(operation) /-10°∽60°C /14°∽140°F(storage)
Humidity	20 - 85% (operation) ) 20 - 90% (storage)
