Wired Barcode Reader Handheld

$37.00

≥1 Others
$32.00

≥50 Others
$27.00

≥200 Others

Options:

WNC-7080g

Get Latest Price

Basic Info

Model No.	WNC-7080g
Brand Name	WINSON
Certification	Ce
product status	Stock
Types of	Barcode Scanner
Scanning element type	Ccd, Cmos
Color point	32 Bit
Interface Type	Usb
place of origin	China
Warranty period (years)	1-Year
After-sales service	Call Center And On-Line Technical Support
Private Mold	Yes
Products Status	Stock
Type	CCD Code Scanner
Scan Element Type	Ccd
Colour Depth	32 Bit
Interface Type	usb, COM, PS/2
Max Paper Size	N/A
Optical Resolution	2500pix
Scan Speed	350±50 (scans/second)
Brand Name	Winson
Place Of Origin	Guangdong, China
Warranty(Year)	1-Year
After-sales Service	Call Center And On-Line Technical Support
Product Name	CCD Code Scanner
Interface	USB HID KEYBOARD/USB VCP/RS-232
Light Source	632nm red LED
Photo sensor	CCD linear sensor
Min resolution	0.101mm/4mil(PCS 0.9)
Min .PCS value	>30%UPC/EAN 13(13mil)
Dimensions (LWH)	108mm * 71mm * 185mm
Weight	168.8g
Mechanical shock	3m drop onto concrete surface

Product description

General Barcode Scanner Support to put prefix or suffix before or after scanned data,turn on/ off buzzer, identity barcode type, add keyboard keys (TAB, CR&LF, etc.)

Laser Barcode Reader Application fields:Supermarket, Retail, Warehouse,Logistic,Library, Medical etc.

Scanner Mount With mini USB receiver, plug and play, Ergonomic design, comfortable to hold.

1d Barcode Module Built-in 2600mAh battery, super-long standby time.

Product Description

Specification

Interface Supported	RS-232/USB HID KEYBOARD/USB VCP
Input Voltage	DC 5V±10%
Current	Max:135mA
Image Sensor	CCD Linear Sensor
Sensor Resolution	2500pixels
Light Source	632nm Red LED
Decoding rate:	350 scans/second±20 scans/second
Scanning Angle	Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40°
